- Page 1 FR Family, MB91460 Emulation System Doc. No. 002-05146 Rev. *A Cypress Semiconductor 198 Champion Court San Jose, CA 95134-1709 http://www.cypress.com...
- Page 2 Cypress Semiconductor Corporation assumes no responsibility for the use of any circuitry other than circuitry embodied in a Cypress product. Nor does it convey or imply any license under patent or other rights. Cypress products are not warranted nor intended to be used for medical, life support, life saving, critical control or safety applications, unless pursuant to an express written agreement with Cypress.
-
Page 3: Table Of Contents
Default Jumpers Settings of the probe cable PB-91467D-LS-208PFV ..............24 Softune Workbench Getting Started .......................... 25 Copying the “template” directory .......................... 25 Adjusting the project files ............................. 25 Opening the Softune Workbench ......................... 26 Entering the code..............................28 FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... - Page 4 Configuring Operating System “Windows ”................... 35 7.3.3 7.3.4 Checking the network-connection ......................38 7.3.5 Troubleshooting ............................38 7.3.6 Softune Workbench ..........................40 Revision History ................................... 41 Document Revision History ............................41 FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A...
-
Page 5: Introduction
1. Introduction The chapter gives short overview of this guide This user guide describes the first steps how to use the MB91460 emulation system. It describes also the software and hardware installation procedure. Further information can be found in the following manuals: „Softune Workbench Installation Manual for V6‟... -
Page 6: Hardware Requirements
2. Hardware Requirements The chapter lists the required hardware for the MB91460 emulation system. The MB91460 emulator system consists of The emulator MB2198-01 incl. 16 V DC power supply The DSU-FR cable MB2198-10 The MB91V460 adapter board (MB2198-300) incl. 16 V DC power supply ... -
Page 7: Software Installation
(Leave blank Body paragraph marker here to add space between opening sentences and main content of chapter.) Rule 1: To install the software under Windows XP/2000/NT 4.0, the user requires administration authority. FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... -
Page 8: Installation Of The Emulation System
Jumpers of the MB91V460 adapter board (MB2198-300) and all jumpers of the evaluation board SK-91460- MAIN V1.2 or SK-91F467D-208PFV and the probe cable PB-91467D-208PFV influencing the adapter board are described in chapter 5. FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... -
Page 9: Connecting The Emulation System
Finally, connect the 16 V DC power supplies (5) to the port „DC in‟ (6) and to 230 V. Please, be aware, that the emulator is switched off. Figure 4-2 illustrates the necessary connections of the emulator MB2198-01. Figure 4-2. Connections of the Emulator MB2198-01 FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... -
Page 10: Mounting The Evaluation Mcu
Connecting the Adapter Board to the SK-91460-MAIN Connect both boards. Be aware, that the boards are tight connected. Figure 4-4 shows the connected boards. Figure 4-4. Connected Adapter Board and Evaluation Board FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... - Page 11 Unscrew the YQ-PACK of the SK-91F467D-208PFV and remove carefully the microcontroller from the socket. Connect the probe cable PB-91467D-208PFV to the SK-91F467D-208PFV and tighten the screw. The same procedure applies for the probe cable PB-91467D-LS-208PFV. FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A...
- Page 12 Provide the 9 V DC power supply and connect it to 230 V. The following figure shows the correct polarization. Do not power up the evaluation board by connecting the power supply yet. Figure 4-8. The Correct Polarization of the 9 V DC Power Supply FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A...
-
Page 13: Power Up The Emulation System
Power on the MB91V460 Adapter Board (MB2198-300) „SW2 Power‟. The „Power‟ LED has to be illuminated. Power on the evaluation board SK-91460-MAIN V1.2 Rule 3: To power down the emulation system, please follow the procedure reversely. FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... -
Page 14: Jumpers And Switches
ADC_SEL: Depending on the voltage supply the respective ADC have to be selected. HWWDG_KILL: The hardware watchdog has to be enabled also in the Softune workbench. (Debug Mode: Setup-> Dev. Environment-> Dev. Environment-> Execution-> watchdog) FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... -
Page 15: Emulator Interface
S15 = TRSTX–ICE S20 = OFF-BREAK S16 = OFF–ICD3 S17 = OFF–ICD2 S18 = OFF–ICD1 S19 = OFF–ICD0 Note: If the in-circuit-emulator (ICE) is used, the default settings have to be used. FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... -
Page 16: External Emulation Memory
8 MByte S11 MDENS0 4 MByte S12 MDENS2 2 MByte 1 MByte 512 kByte Prohibited Prohibited 0 Byte Default: S13 = D32-X MDENS0 = 0 MDENS1 = 0 MDENS2 = 0 FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... -
Page 17: Clock Control
S25 = EML-X1A S30 = MCLKI-USER S31 = MCLKO-USER By default the clocks are provided from the adapter board. By default MCLKI and MCLKO are connected to the evaluation board. FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... -
Page 18: Power Settings
P24_3 is connected to CN2_B67 P243 – CN2_B67 S21 = PULLDOWN – P10_7 Default: S32 = P224 – CN2_B68 S33 = P242 – CN3_A6 S34 = P225 – CN2_B67 S35 = P243 – CN3_A5 FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... -
Page 19: Default Jumper Settings
In Figure 5-1 the default jumper settings of the adapter board are marked. The resistor can be removed, beside of R71, R74 and R75. Figure 5-1. Default Jumper Settings of the Adapter Board FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... -
Page 20: Jumpers Of The Evaluation Board Sk-91460-Main V1.2
By default, the I/O-ports are supplied by 5 V. Note: The Jumper S28 of the adapter board selects UVCC3 or MCU_VCC (UVCC5) as power supply for the I/O- port. By default this Jumper selects MCU_VCC (UVCC5). FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... -
Page 21: Default Jumper Settings
In Figure 5-2 the default jumper settings are marked. For detailed information about the jumpers, please refer to the hardware manual of the evaluation board. Figure 5-2. Default Jumper Settings of the Evaluation Board SK-91460-MAIN FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... -
Page 22: Default Jumper Settings Of The Evaluation Board Sk-91F467D-208Pfv
In the following figure the default jumper settings are marked. For detailed information about the jumpers, please refer to the user guide of the evaluation board. Figure 5-3. Default Jumper Settings of the Evaluation Board SK-91F467D-208PFV FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... -
Page 23: Default Jumpers Settings Of The Probe Cable Pb-91467D-208Pfv
In the following figure the default jumper settings are marked. For detailed information about the jumpers, please refer to the user guide of the evaluation board. Figure 5-4. Default Jumper Settings of the Probe Cable PB-91467D-208PFV FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... -
Page 24: Default Jumpers Settings Of The Probe Cable Pb-91467D-Ls-208Pfv
In the following figure the default jumper settings are marked. For detailed information about the jumpers, please refer to the user guide of the evaluation board. Figure 5-5. Default Jumper Settings of the Probe Cable PB-91467D-LS-208PFV FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... -
Page 25: Softune Workbench Getting Started
First click into the new “LED” folder and rename the following files: Template.prj Led.prj Template.wsp Led.wsp Now open the file “Led.prj” with your favorite text editor. You will find an entry like this: [DirInfo] PRJ=C:\ FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... -
Page 26: Opening The Softune Workbench
Choose the Menu File/Open. The following pop up window will occur: Figure 6-2. Open a Workspace Click “OK” for “Workspace/Project file”, and then browse to the file “Led.wsp”. Open it. FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... - Page 27 Open the Source File of the Main Program “Main.c” by double clicking it in the window shown left. Now a text editor window will open, which shows the contents of “Main.c”. It will look like this: FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A...
-
Page 28: Entering The Code
There are two ways to build to the whole project data. Either choose Project/Build or click the button in the circle in the illustration below: FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... -
Page 29: Enter Debugging Mode
After a successful connection, the Softune Workbench will look like this: Figure 6-4. Debugging Mode after a successful Connection Note: The interface has to be determined only once. Later you can choose the menu Debug/Start debug to enter this mode. FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... -
Page 30: Executing The Program
Note, that in the next start of the Workbench, your new LED-Project will occur in the menu list File/Recent Workspace File. By simply clicking to “Led.wsp”, the whole project will open again. FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... -
Page 31: Setup / Change Connection Pc - Emulation System
After the PC is booted, power up the emulator. Windows will register a new hardware component and will start the hardware wizard. Select the option „No, not this time‟ to search the drivers manually and press „Next‟. FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... - Page 32 Setup / Change Connection PC – Emulation System Figure 7-1. Installing the USB-driver I Select the option „Install from a list or specific location (Advanced) and press „Next‟ Figure 7-2. Installing the USB-driver II FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A...
- Page 33 Figure 7-3. Choose the search options Finish the update procedure by pressing „Finish‟. Figure 7-4. Close the hardware wizard Rule 4: To install the software under Windows XP/2000/NT 4.0, the user requires administration authority. FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A...
-
Page 34: Setup Lan
Using the Cypress LAN-remote controlled debug facility, A Cypress support engineer can easily help solving a concrete problem by debugging your application out of a Cypress support centre. You can control the emulator from different locations without having to move your hardware installation from one place to another. -
Page 35: Configuring Operating System "Windows
(Note: The files may not have a file-extension!) Make a copy off all three files, like for an example: services to sevices.old , etc. Edit file services and add the following line: fjicesv 5001/tcp # Cypress emulator FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... - Page 36 This may be important if you use a DNS-Server. Of course, you can define different names for the same IP-Address, as shown below. Edit file hosts and add the following line: “The unique IP address (as set by LAN-Address, see above)” “Nickname of emulator” e.g. 141.187.6.82 Emulator FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A...
- Page 37 The file lmhosts (or lmhosts.sam) is used to make a redefinition of the complex IP-number with a simple name within your local network. Of course, you can define different names for the same IP-Address, as shown below. Edit file lmhosts and add the following line: FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A...
-
Page 38: Checking The Network-Connection
Also check your physical network interconnection cables. When using a HUB for 10Base-T then a standard (1:1) network cable has to be used. If the emulator is connected directly to the PC a “crossed network cable” is necessary. Good answer: Emulator/LAN-adapter replies with time-values: FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... - Page 39 Setup / Change Connection PC – Emulation System Figure 7-9. Testing the IP-Connection to the Emulator I “Failed”-answer: Emulator/LAN-adapter replies with timeout message: Figure 7-10. Testing the IP-Connection to the Emulator II FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A...
-
Page 40: Softune Workbench
Host: can be the “nickname” as defined in the files hosts and lmhosts or the IP-address of the emulator, set by the program “LAN-Address”, can be used. Figure 7-11. Changing the IP-Address of the Host in the Softune Workbench Nickname or IP address FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A... -
Page 41: Revision History
V1.8; UMa: Corrected typo in defaults of 5.1.2 Emulator interface. Table was Corrected. 12/14/2007 V1.9 UMa: Corrected number of document 01/19/2016 NOFL Migrated Spansion Guide from MCU-AN-300005-E-V19 to Cypress format FR Family, MB91460 Emulation System, Doc. No. 002-05146 Rev. *A...
