The following document contains information on Cypress products. The document has the series
name, product name, and ordering part numbering with the prefix "MB". However, Cypress will
offer these products to new and existing customers with the series name, product name, and
ordering part number with the prefix "CY".
How to Check the Ordering Part Number
1.
Go to www.cypress.com/pcn.
2.
Enter the keyword (for example, ordering part number) in the SEARCH PCNS field and click
Apply.
3.
Click the corresponding title from the search results.
4.
Download the Affected Parts List file, which has details of all changes
For More Information
Please contact your local sales office for additional information about Cypress products and
solutions.
About Cypress
Cypress is the leader in advanced embedded system solutions for the world's most innovative
automotive, industrial, smart home appliances, consumer electronics and medical products.
Cypress' microcontrollers, analog ICs, wireless and USB-based connectivity solutions and reliable,
high-performance memories help engineers design differentiated products and get them to market
first. Cypress is committed to providing customers with the best support and development
resources on the planet enabling them to disrupt markets by creating new product categories in
record time. To learn more, go to www.cypress.com.
Advertisement
Table of Contents
Related Manuals for Cypress MB91460 Series
Summary of Contents for Cypress MB91460 Series
- Page 1 The following document contains information on Cypress products. The document has the series name, product name, and ordering part numbering with the prefix “MB”. However, Cypress will offer these products to new and existing customers with the series name, product name, and ordering part number with the prefix “CY”.
-
Page 2: Table Of Contents
Softune Workbench Simulator ........ 16 Introduction The MB91461R is a ROMless derivate of the Cypress FR-MB91460 Series. It has a complete debug support unit (DSU4) integrated like the evaluation chip MB91V460. This is a major difference to other MB91460 series members. - Page 3 FR Family MB91460 Series MB91461R Emulation Figure 1. Evaluation System with Eva-Chip Header Board MB2198-301 Adapter Board MB2198-300 with EVA- Chip MB91V460 Starterkit SK91461 (with socket) DSU-Cable MB2198-10 Emulator MB2198-01 The following tables show the needed jumper settings on adapter and header board for use of the starterkit SK91461: Table 1.
- Page 4 FR Family MB91460 Series MB91461R Emulation Name Setting Name Setting D32_D16SL MCLKO INITX P224 Connection TRSTX P242 Connection ICD3 PD_OFF P225 Connection ICD2 PD_OFF P243 Connection ICD1 PD_OFF Table 2. Jumper settings on header board MB2198-301 Name Setting VCCB1 VCC5H...
- Page 5 FR Family MB91460 Series MB91461R Emulation Figure 2. Select project configuration STANDALONE_EVALUATION If you do not use the template project, please check following setting on ‘MCU’ tab of the ‘Setup Project’ dialog (‘Project’ -> ‘Setup Project…’) and change bus mode to invalid.
-
Page 6: Evaluation System With Mb91461R
FR Family MB91460 Series MB91461R Emulation Figure 4. Enable external memory emulation Enable external memory emulation for chip select 0 area as RAM type. This will force the evaluation MCU to use the external SRAM on MB2198-300, which is connected to the external bus, as memory for the debug session. - Page 7 FR Family MB91460 Series MB91461R Emulation Figure 5. Evaluation system with MB91461R Starterkit SK91461 with MB91461R DSU-Cable MB2198-10 Emulator MB2198-01 Connection of the DSU pins of the microcontroller to the DSU connector is shown in MB91461R hardware manual, chapter 2.2.
- Page 8 FR Family MB91460 Series MB91461R Emulation Table 4. Assignment of DSU Pins to Connector Please select project configuration type STANDALONE if your project is based on the MB91461R template project. Figure 7. Select project configuration STANDALONE Otherwise please check the following items under ‘Project’ ->‘Setup Project…’ -> ‘MCU’ tab: www.cypress.com...
-
Page 9: Emu_Flash_Cs0_Usb.sup
FR Family MB91460 Series MB91461R Emulation ▪ Bus Mode: External ROM external Bus ▪ Bus width: 16bit Figure 8. Configure Bus Mode External ROM This kind of emulation system can be used in two different ways: ▪ The external Flash memory on SK91461 (4MB) connected to CS0 can be used ▪... - Page 10 FR Family MB91460 Series MB91461R Emulation Table 5. Jumper and switches on SK91461 for Flash programming Name (Switches) Setting P15_3 P15_2 Don’t care INT0 Name (Jumpers) Setting P21_0 Connection P21_1 Connection P15_3 Connection P15_2 Connection Press the ‘Full Operation’ button and follow the instructions. Please refer to the programmer description for more details.
- Page 11 FR Family MB91460 Series MB91461R Emulation After Flash programming you can disconnect the serial cable and change the settings back to: Table 6. Jumper and switches on SK91461 Flash Emulation Name (Switches) Setting Don’t care P15_3 Don’t care P15_2 Don’t care...
-
Page 12: Emu_Sram_Cs1_Usb.sup
FR Family MB91460 Series MB91461R Emulation Attention: You have to care that the programmed mhx-file as well as the debug information taken from the abs-file originate from the same project! EMU_SRAM_CS1_USB.sup This debug configuration uses the external SRAM memory connected to CS1 area of the microcontroller. - Page 13 FR Family MB91460 Series MB91461R Emulation Figure 10. Standalone usage with monitor debugger Starterkit SK91461 with MB91461R The monitor debugger kernel initializes the CS1 area for the SRAM on starterkit to download the user project. If your project is based on the MB91461R template project, choose project configuration MONDEB. Otherwise you will have to take care that your code and data sections are linked to the CS1 area configured by the monitor debugger kernel.
-
Page 14: Accemic Mde Monitor Debugger
FR Family MB91460 Series MB91461R Emulation Table 8. Jumper and switches on SK91461 for SWB Monitor Debugger Name (Switches) Setting Don’t care P15_3 Don’t care P15_2 INT0 Name (Jumpers) Setting P21_0 Connection P21_1 Connection Don’t care P15_3 Don’t care P15_2 To start debug session connect UART0 via crossed serial cable to your PC’s COM port and double-click the... - Page 15 FR Family MB91460 Series MB91461R Emulation Table 9. Jumper and switches on SK91461 for Accemic MDE Monitor Debugger Name (Switches) Setting Don’t care P15_3 Don’t care P15_2 INT0 Name (Jumpers) Setting P21_0 Connection P21_1 Connection Don’t care P15_3 Don’t care P15_2 As first step you have to select processor type.
- Page 16 FR Family MB91460 Series MB91461R Emulation If the kernel download ended successfully, set microcontroller back to run mode (see table 9). Click ‘+’ button in projects window and add your project. Figure 12. Select project Start connection to the monitor kernel via ‘Debug’ -> ‘Connect’. After connection is set up, download your application to the microcontroller (‘Debug’...
-
Page 17: Softune Workbench Simulator
FR Family MB91460 Series MB91461R Emulation Figure 14. GUI of Accemic MDE Monitor Debugger Softune Workbench Simulator This chapter describes the debugging functionality of the Softune Workbench Simulator. Softune Workbench includes a core simulator. This simulator can be used to debug all core related functions of your application. -
Page 18: Comparison Table
FR Family MB91460 Series MB91461R Emulation Comparison Table This chapter gives a rough overview about needed internal or peripheral resources for debugging and debugging functionality of the different possibilities. Debug Type Resource/ Functionality Target Chip MB91461RA Evaluation Chip MB91V460 Adapter Board MB2198-300... -
Page 19: Document History
FR Family MB91460 Series MB91461R Emulation Document History Document Title: AN205206 - FR Family MB91460 Series MB91461R Emulation Document Number: 002-05206 Revision Orig. of Submission Description of Change Change Date 04/27/2006 Initial release NOFL updates based on template “91460_template_91461r-v14” 04/26/2007... -
Page 20: Worldwide Sales And Design Support
Cypress is not liable, in whole or in part, and you shall and hereby do release Cypress from any claim, damage, or other liability arising from or related to all Unintended Uses of Cypress products.
