Installation Manual
Color LCD Monitor
Important
Please read this "Installation Manual", and "Instructions for Use"
(separate volume) carefully to familiarize yourself with safe and
effective usage.
• Refer to the "Instructions for Use" for information on the installation /
connection of the monitor.
• For the latest product information including the "Installation Manual",
refer to our web site :
www.eizoglobal.com
Advertisement
Table of Contents
Related Manuals for Eizo RadiForce MX216
Summary of Contents for Eizo RadiForce MX216
- Page 1 Installation Manual Color LCD Monitor Important Please read this “Installation Manual”, and “Instructions for Use” (separate volume) carefully to familiarize yourself with safe and effective usage. • Refer to the “Instructions for Use” for information on the installation / connection of the monitor. •...
- Page 2 EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.
-
Page 3: Table Of Contents
Adjusting the contrast ........11 ● Adjusting the color temperature .....12 5-12. Setting Whether to Display / Hide the ● EIZO Logo ............ 24 Adjusting the gamma ........12 ● Adjusting the hue ...........13 5-13. Viewing the Monitor Information ....24 ●... -
Page 4: Chapter 1 Basic Operation And Function List
Chapter 1 Basic Operation and Function List 1-1. Usage of Switches and Operation Guide Displaying the operation guide Touch any switch (except The operation guide appears on the screen. Display Function Turns the power on or off. Displays the Setting menu. The Setting menu is used to configure advanced monitor settings. -
Page 5: Basic Operation Of The Setting Menu
1-2. Basic Operation of the Setting Menu Displaying the Setting menu 1. Select from the operation guide. The Setting menu appears. Note • To adjust or set "Administrator Settings" items, display the Setting menu according to the following procedure: 1. Select to turn off the monitor. - Page 6 3. Perform adjustment/setting with , and select to accept the changes. Note • The settings for "Administrator Settings" items are applied by selecting "Apply". Exiting Select several times to exit the Setting menu. Note • The menu for "Administrator Settings" items is exited by selecting "Apply". Chapter 1 Basic Operation and Function List...
-
Page 7: Function List
“5-1. Specifying the Language” (page 19) Information “5-13. Viewing the Monitor Information” (page 24) Administrator On-Screen Logo “5-12. Setting Whether to Display / Hide the EIZO Logo” Settings (page 24) Key Lock “5-9. Locking Operation Switches” (page 22) Image Rotation “5-5. -
Page 8: Chapter 2 Adjusting The Screen
Chapter 2 Adjusting the Screen 2-1. Compatible Resolutions For information about the compatible resolutions of the monitor, see “Compatible Resolutions” in the Instructions for Use. 2-2. Setting the Input Signal You can select an input signal to be displayed on the screen. Procedure 1. -
Page 9: Selecting Display Mode (Cal Switch Mode)
2-3. Selecting Display Mode (CAL Switch Mode) The display mode can be selected according to the monitor application. Display Modes √: Can be calibrated Mode Purpose ® 1-DICOM Enables display using DICOM Part 14-compliant grayscale characteristics. √ 2-CAL1 Displays the calibration status using calibration software. √... -
Page 10: Adjusting Brightness / Colors
2-4. Adjusting Brightness / Colors You can adjust brightness and colors for each mode, and save the settings. Attention • It takes about 15 minutes for the electrical parts in the product to become stable. Please wait 15 minutes or more after the monitor power has been turned on or the monitor has recovered from the power saving mode before performing adjustment. -
Page 11: Enabling Or Disabling Hybrid Gamma Pxl
● Enabling or disabling Hybrid Gamma PXL When the Hybrid Gamma PXL function is enabled, this product automatically differentiates between monochrome and color parts of the same image at a pixel level, and displays a color image using the gamma value for color image display. Setting Range On, Off Procedure... -
Page 12: Adjusting The Color Temperature
● Adjusting the color temperature Adjust the color temperature. The color temperature is normally used to express the hue of “White” and / or “Black” with a numerical value. The value is expressed in degrees “K” (Kelvin). The screen becomes reddish at low color temperatures and bluish at high color temperatures, similar to the temperatures of a flame. -
Page 13: Adjusting The Hue
● Adjusting the hue Adjust the hue. Setting Range -100 to 100 Procedure 1. Select “CAL Switch Mode” from the Setting menu, then select 2. Select “Hue”, then 3. Specify the setting using 4. Select after completing the setting. Attention •... -
Page 14: Adjusting The Gain
• When gain is changed, the color temperature is changed to “User”. 2-5. Enabling or Disabling Sharpness Recovery (the Function of Correcting Image Clarity) EIZO’s unique technology called “Sharpness Recovery” displays images that are true to the original source data by correcting variations in the LCD panel. Procedure 1. -
Page 15: Chapter 3 Controlling Monitor Quality
"RadiCS UX1". • To adjust measurement results of the Integrated Front Sensor to those of an EIZO external sensor (UX1 or UX2 sensor), perform correlation between the Integrated Front Sensor and the external sensor using RadiCS / RadiCS LE. -
Page 16: Checking The Selfcalibration Results
● Checking the SelfCalibration results Attention • The results can be checked when "QC History" is set to "On" (see “3-3. Setting Whether to Display / Hide Warnings or QC History” (page 17)). Procedure 1. Select “RadiCS SelfQC” from the Setting menu, then select 2. -
Page 17: Checking The Grayscale Check Results
● Checking the Grayscale Check results Attention • The results can be checked when "QC History" is set to "On". Procedure 1. Select “RadiCS SelfQC” from the Setting menu, then select 2. Select “Grayscale Check”, then 3. Select “Result”, then 4. -
Page 18: Chapter 4 Using The Monitor For A Long Time
Chapter 4 Using the Monitor for a Long Time The monitor can be set to enter the power saving mode according to the PC status. The life of the monitor backlight can be extended by setting the monitor to enter the power saving mode when the monitor is not used. -
Page 19: Chapter 5 Configuring Monitor Settings
Chapter 5 Configuring Monitor Settings 5-1. Specifying the Language The language for the Setting menu and messages can be selected. Selectable Languages English, Germany, French, Spanish, Italian, Swedish, Japanese, Chinese (simplified), Chinese (traditional) Procedure 1. Select “Languages” from the Setting menu, then select 2. -
Page 20: Switching The Display Size
5-3. Switching the Display Size You can set the size when displaying images at other than the recommended resolution. Example: Full Screen Aspect Ratio Dot by Dot Procedure 1. Select “Signal” from the Setting menu, then select 2. Select “Picture Expansion”, then 3. -
Page 21: Setting The Image Display Orientation
5-5. Setting the Image Display Orientation This function allows you to change the image display orientation according to the monitor installation orientation. Procedure 1. Select to turn off the monitor. 2. While touching the leftmost switch ( ), touch for more than two seconds to turn on the monitor. -
Page 22: Enabling Or Disabling Displayport Communication In Power Saving Mode
5-8. Enabling or Disabling DisplayPort Communication in Power Saving Mode Connecting a PC to the DisplayPort connector enables DisplayPort communication, and thus consumes high power even in the power saving mode. The communication can be disabled by setting “DP Power Save”... -
Page 23: Setting Whether To Display / Hide The Grayscale Warning
5-10. Setting Whether to Display / Hide the Grayscale Warning You can specify whether to display the Grayscale Display Error message to indicate that a 6-bit (64-grayscale) signal has been detected when the DisplayPort signal is input at the recommended resolution. -
Page 24: Setting Whether To Display / Hide The Eizo Logo
5-12. Setting Whether to Display / Hide the EIZO Logo You can select whether to display or hide the EIZO logo when the monitor starts. Procedure 1. Touch to turn off the monitor. 2. While touching the leftmost switch (... -
Page 25: Resetting To Defaults
5-14. Resetting to Defaults There are two different reset functions: One that only resets the color adjustments to default settings, and the other that resets all settings to defaults. Attention • The previous settings cannot be recovered after they were reset to defaults. Note •... -
Page 26: Chapter 6 Troubleshooting
• Turn off the main power, and then turn it on again. • Power switch indicator blinks: Orange, • Connect via the signal cable specified by EIZO. Turn off the Green main power, and then turn it on again. -
Page 27: Imaging Problems
(The LCD monitor backlight has a limited life span. When the screen becomes dark or begins to flicker, contact your local EIZO representative.) 2. Text is blurred • Check whether the PC is configured to meet the resolution and vertical scan frequency requirements of the monitor (see “Compatible Resolutions”... -
Page 28: Other Problems
• Try changing to a different USB port on the monitor. • Reboot the PC. • If the peripheral works normally when directly connected to the PC, contact your dealer or local EIZO representative. • Check whether the PC and OS are USB compliant. (For USB compliance of the respective devices, consult their manufacturers.) -
Page 29: Error Code Table
● Error Code Table Error Code Description ****50 • The maximum brightness of the monitor may be lower than the target brightness. • Try reducing the target brightness. ****52 • The minimum brightness of the monitor may be higher than the target minimum brightness. -
Page 30: Chapter 7 Reference
Chapter 7 Reference 7-1. Arm Installation Procedure An optional arm (or an optional stand) can be attached by removing the stand section. Please refer to our web site for the supported optional arm (or optional stand). www.eizoglobal.com Attention • When attaching an arm or stand, follow the instructions of the respective User’s Manual. •... -
Page 31: How To Use Usb Hub Function
7-2. How to Use USB Hub Function This monitor is equipped with a USB hub. Connected to a PC compatible with USB or another monitor with a USB hub, this monitor functions as a USB hub allowing connection to peripheral USB devices. Connection procedure 1. -
Page 32: Main Default Settings
7-3. Main Default Settings CAL Switch Mode: Factory default display setting is “1-DICOM”. Hybrid Gamma Mode Brightness Temperature Gamma value 1-DICOM 270 cd/m 7500 K DICOM GSDF 2-CAL1 270 cd/m 7500 K 3-CAL2 180 cd/m 7500 K DICOM GSDF 4-Custom Approx. -
Page 33: Appendix
Apple, macOS, Mac OS, OS X, Macintosh and ColorSync are registered trademarks of Apple Inc. EIZO, the EIZO Logo, ColorEdge, CuratOR, DuraVision, FlexScan, FORIS, RadiCS, RadiForce, RadiNET, Raptor and ScreenManager are registered trademarks of EIZO Corporation in Japan and other countries. -
Page 34: Limited Warranty
(hereinafter referred to as the “Product”) from EIZO or Distributors, that EIZO and Distributors shall, at their sole discretion, either repair or replace the Product at no charge if the Original Purchaser becomes aware within the Warranty Period (defined below) that (i) the Product malfunctions or is damaged in the course of normal use of the Product in accordance with the description in the instruction manual of the Product (hereinafter referred to as the “User’s Manual”), or (ii) the LCD panel and brightness of the Product cannot maintain the... -
Page 35: Recycling Information
Este producto debe desecharse y reciclarse según la legislación del país para reducir el impacto medioambiental. Cuando desee deshacerse de este producto, póngase en contacto con un distribuidor o una filial de su país. Encontrará las direcciones de contacto en el sitio web de EIZO que se indica a continuación. www.eizoglobal.com... - Page 36 Este produto, quando o deitar fora, deve ser recolhido e reciclado de acordo com a legislação do seu país para reduzir a poluição. Quando deitar fora este produto, contacte um distribuidor ou uma filial no seu país. Os endereços de contacto estão listados no website do EIZO, abaixo. www.eizoglobal.com...
- Page 37 страна за да се намали замърсяването на околната среда. Когато искате да се освободите от този продукт, моля свържете се с търговския му представител или със съответните органи отговарящи за това във вашата страна. Данните за връзка с нас са описани на следния Интернет сайт на EIZO: www.eizoglobal.com Informaţie referitoare la reciclare Acest produs, când debarasat, trebuie colectat şi reciclat conform legislaţiei ţării rspective ca să...
- Page 38 Geri Dönüşüm Bilgisi Bu ürünün, atılacağı zaman, ülkenizin çevre kirliliğinin azaltılması konusundaki mevzuatına göre toplanması ve yeniden değerlendirilmesi gerekmektedir. Ürünü atacağınız zaman lütfen ülkenizdeki bir distribütör veya ilgili kuruluşla temasa geçiniz. İrtibat adresleri aşağıdaki EIZO web sitesinde verilmiştir. www.eizoglobal.com Appendix...
- Page 39 03V27375A1 IM-MX216 Copyright © 2019 EIZO Corporation. All rights reserved. 1st Edition-January 2019...
