Important
Please read this User's Manual carefully to
familiarize yourself with safe and effective

usage procedures.

Please retain this manual for future
reference.
SAFETY SYMBOLS .................................................... 2
PRECAUTIONS ...................................................... 3
1. Introduction .............................................................. 7
1-1. Features .............................................................. 7
1-2. Buttons and Indicators ........................................ 8
1-3. Utility Disk ........................................................... 9
2. Installation .............................................................. 10
3. Screen Adjustment and Settings ........................... 12
3-1. Basic Operation and Functions ......................... 12
3-2. Screen Adjustment ............................................ 14
3-3. Color Adjustment ............................................... 17
3-4. Power-save Setup ............................................. 20
3-5. Off Timer ........................................................... 21
3-6. Locking the settings........................................... 21
3-7. Power Indicator Setting ..................................... 22
3-8. Automatic brightness adjustment ...................... 22
3-9. Displaying Lower Resolutions ........................... 23
3-11. EIZO Logo Appearing Function ....................... 24
4.Troubleshooting ...................................................... 25
5. Reference .............................................................. 28
5-1. Attaching an arm ............................................... 28
5-2. Cleaning ............................................................ 29
5-3. Specifications .................................................... 30
5-4. Glossary ............................................................ 33
6. APPENDIX/ANHANG/ANNEXE ............................ 35
About TCO'03 ............................................................ 36
FCC Declaration of Conformity .................................. 37
Schwenkarms für Ihren Monitor /
Hinweis zur Ergonomie .............................................. 38

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FlexScan MX210 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eizo FlexScan MX210

Summary of Contents for Eizo FlexScan MX210

  • Page 1: Table Of Contents

    3-8. Automatic brightness adjustment ...... 22 3-9. Displaying Lower Resolutions ......23 3-10. Setting the orientation of the Adjustment menu ..24 3-11. EIZO Logo Appearing Function ....... 24 4.Troubleshooting ............25 5. Reference .............. 28 5-1. Attaching an arm ..........28 5-2.

  • Page 2: Safety Symbols

    Indicates a prohibited action. Indicates to ground for safety. Copyright© 2007 EIZO NANAO CORPORATION All rights reserved. No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, or otherwise, without the prior written permission of EIZO NANAO CORPORATION.

  • Page 3: Precautions

    PRECAUTIONS PRECAUTIONS IMPORTANT! • This product has been adjusted specifically for use in the region to which it was originally shipped. If operated outside the region to which it was originally shipped, the product may not perform as stated in the specifications. This product is designed for use in Japan only and cannot be used in any other countries.
  • Page 4 PRECAUTIONS WARNING Place the unit at the strong and stable place. A unit placed on an inadequate surface may fall and result in injury or equipment damage. If the unit falls, disconnect the power immediately and ask your dealer for advice. Do not continue using a damaged unit.
  • Page 5 PRECAUTIONS WARNING When attaching an arm stand, please refer to the user's manual of the arm stand and install the unit securely. Not doing so may cause the unit to come unattached, which may result in injury or equipment damage. When the unit is dropped, please ask your dealer for advice. Do not continue using a damaged unit.

  • Page 6: Lcd Panel

    PRECAUTIONS LCD Panel In order to suppress the luminosity change by long-term use and to maintain the stable luminosity, use of a monitor in lower brightness is recommended. The LCD panel is manufactured using high-precision technology. However, note that the appearance of any missing pixels or lit pixels does not indicate damage to the LCD monitor.

  • Page 7: Introduction

    EIZO LCD Utility Disk). • The utility software "ScreenManager Pro for Medical" (for Windows) to control the monitor from a PC with mouse/keyboard is included (refer to the EIZO LCD Utility Disk). • Height adjustable stand • Ultra slim bezel...

  • Page 8: Buttons And Indicators

    6. Enter button 7. Control buttons (Left, Down, Up, Right) 8. Power button 9. Power indicator Indicator status Operation status Blue The screen is displayed Orange Power saving Power off *ScreenManager is an EIZO's nickname of the Adjustment menu. ®...

  • Page 9: Utility Disk

    1. Introduction 1-. Utility Disk An "EIZO LCD Utility Disk" (CD-ROM) is supplied with the monitor. The following table shows the disk contents and the overview of the application software programs. Disk contents and software overview The disk includes a monitor information file, application software programs for adjustment, and User’s Manual.

  • Page 10: Installation

    2. Installation . Installation -1. Connecting Two PCs to the Monitor Two PCs can be connected to the monitor through the DVI-I connector on the back of the monitor. Connection examples DIV-I D-sub mini connector 15-pin Connector (SIGNAL1) (SIGNAL2) PC 1 PC  Signal Cable Signal Cable...

  • Page 11: Making Use Of Usb (Universal Serial Bus)

    2. Installation -. Making Use of USB (Universal Serial Bus) This monitor provides a hub which supports the USB standard. When connecting to a USB compliant PC or another hub, the monitor functions as a hub to which the USB compliant peripherals can be easily connected.

  • Page 12: Screen Adjustment And Settings

    3. Screen Adjustment and Settings . Screen Adjustment and Settings -1. Basic Operation and Functions ScreenManager allows you to adjust screen performance though the main menu and select a CAL Switch mode easily. ® Adjustment menu (ScreenManagaer Power button Enter button CAL Switch Menu Control buttons Mode button...
  • Page 13 3. Screen Adjustment and Settings Functions The following table shows all the ScreenManager's adjustment and setting menus. "*" indicates adjustments of analog input only and "**" indicates digital input only. Main menu Sub menu Reference Screen Clock 3-2. Screen Adjustment Phase Position Resolution...

  • Page 14: Screen Adjustment

    If the appropriate screen can be made, proceed to 4. Range Adjustment . Run the "Screen Adjustment Program". Having read the "Readme.txt" file, run the "Screen Adjustment Program" in the enclosed EIZO LCD Utility Disk. Step by step, adjustment is provided by the wizard guide. (If using the Windows, the program can be directly run from the menu screen of the CD-ROM.)
  • Page 15 3. Screen Adjustment and Settings Adjust by using <Screen> menu in the ScreenManager (1)Vertical bars appear on the screen Use the <Clock> adjustment. Select the <Clock> and eliminate the vertical bars by using of the Control buttons. Do not continuously press the Control buttons, as the adjustment value will change quickly and make it difficult to locate the most suitable adjustment point.
  • Page 16 3. Screen Adjustment and Settings (4)Screen image is smaller or larger than the actual screen images. Use the <Resolution> adjustment. Adjustment is needed when the input signal resolution and the resolution now being displayed are different. Select <Resolution> and confirm if the resolution now being displayed is the same as the input resolution.

  • Page 17: Cal Switch Mode

    3. Screen Adjustment and Settings -. Color Adjustment Simple adjustment [CAL Switch mode] This function allows you to select the best display mode for monitor brightness, etc. To select CAL Switch mode Directly pressing allows you to select the best suited mode for screen display from 4 CAL Switch modes;...
  • Page 18 3. Screen Adjustment and Settings Advanced Adjustments[Adjustment menu] Color settings of each CAL Switch mode can be adjusted and saved by using the <Color> menu of the Adjustment menu. In the analog input, perform the "Range Adjustment" before making the color adjustments. Never change the CAL Switch mode during color adjustment.
  • Page 19 3. Screen Adjustment and Settings Adjustment Contents Menu Function Descriptions Adjustable range Brightness To set the brightness of the screen 0~100% Tips • The values shown in the “%” are available only as reference. Temperature To set the color temperature 6500K~15000K in 500 K increments (including 9300 K) Tips •...

  • Page 20: Power-Save Setup

    3. Screen Adjustment and Settings -. Power-save Setup The <PowerManager> menu in the ScreenManager enables to set the power-save setup. NOTE • Do your part to conserve energy, turn off the monitor when you are finished using it. Disconnecting the monitor from the power supply is recommended to save energy completely. •...

  • Page 21: Off Timer

    3. Screen Adjustment and Settings -. Off Timer The off timer function causes the monitor to automatically enter a power off state after a predetermined amount of time has lapsed. This function was created to reduce Afterimage characteristics that are particular to LCD monitors when the monitor screen is left on for a long period without use.

  • Page 22: Power Indicator Setting

    3. Screen Adjustment and Settings -. Power Indicator Setting Light off the power indicator. This function is available for the multiple panels settings. [Procedure] 1. Select <Power Indicator> in the ScreenManager <Others> menu. 2. Select "Disable". -. Automatic brightness adjustment The sensor on the front side of the monitor detects the environmental brightness to adjust the screen brightness automatically and comfortably.

  • Page 23: Displaying Lower Resolutions

    3. Screen Adjustment and Settings -. Displaying Lower Resolutions The lower resolutions are enlarged to full screen automatically. Using the <Screen Size> function in the <Others> menu enables to change the screen size. Enlarge the screen size when displaying a low resolution. Select the <Screen Size>. Select the <Screen Size> in the <Others> menu and select the screen size by using Mode Function Full...

  • Page 24: Setting The Orientation Of The Adjustment Menu

    -11. EIZO Logo Appearing Function When switching on the power button on the front control panel, the EIZO logo is displayed for a while. If you desire to display or undisplay this logo, use this function. (Default is logo appearing.) [To undisplay] 1.

  • Page 25: Troubleshooting

    4. Troubleshooting .Troubleshooting If a problem still remains after applying the suggested remedies, contact your local dealer. • No-picture problems : See No.1 - No.2 • Imaging problems : See No.3 - No.14 • Other problems : See No.15 - No.18 •...
  • Page 26 4. Troubleshooting Problems Possible cause and remedy 3. Display position is incorrect. • Adjust image position so that it is displayed properly within the display area using the <Position> adjustment (page 15). • Adjust image position so that it is displayed properly within the display area using the "Hor.Position"...
  • Page 27 • Try executing the following method. •Restarting the PC •Connecting the PC and peripherals directly •If the problem is solved by doing this, contact an EIZO dealer. 20.USB function cannot be setup. • Check that the USB cable is correctly connected.

  • Page 28: Reference

    5. Reference . Reference -1. Attaching an arm The LCD monitor can be used with an arm by removing the tilt stand and attaching the arm stand to the LCD monitor. NOTE • If you will use the arm or stand of other manufacturers, confirm the followings to the manufacturers before selecting.

  • Page 29: Cleaning

    5. Reference -. Cleaning Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime. NOTE • Never use thinner, benzene, alcohol (ethanol, methanol, or isopropyl alcohol), abrasive cleaners, or other strong solvents, as these may cause damage to the cabinet or LCD panel. Cabinet To remove stains, wipe the cabinet with a soft, lightly moistened cloth using a mild detergent.

  • Page 30: Specifications

    5. Reference -. Specifications LCD Panel 54 cm (21.3 inch), TFT color LCD panel Surface treatment : Anti-Glare Surface hardness : 3H Response Time : 16ms Viewing Angle Horizontal : 178°, Vertical : 178° (CR: 10 or more) Dot Pitch 0.270mm Horizontal Scan Analog...

  • Page 31: Default Settings

    5. Reference Default settings Smoothing CAL Switch Mode DICOM-CL PowerManager Analog input : VESA DPMS Digital input:DVI DMPM Screen Size Full Off Timer Disable Menu Settings Menu Size Normal Menu Off Timer 45 seconds BrightRegulator Disable Language English Dimensions mm(inch)

  • Page 32: Pin Assignment

    5. Reference Pin Assignment •DVI-I Connector 1 2 3 4 5 6 7 8 C1 C2 10 11 12 13 14 15 16 C3 C4 17 18 19 20 21 22 23 24 Pin No. Signal Pin No. Signal Pin No. Signal TMDS Data 2- TMDS Data1/3 Shield...

  • Page 33: Glossary

    5. Reference -. Glossary Clock With the analog input signal display, the analog signal is converted to a digital signal by the LCD circuitry. To convert the signal correctly, the LCD monitor needs to produce the same number clock pulse as the dot clock of the graphics system. When the clock pulse is not correctly set, some vertical bars of distortion are displayed on the screen.
  • Page 34 5. Reference Resolution The LCD panel consists of a fixed number of pixel elements which are illuminated to form the screen image. This monitor consists of 1600 horizontal pixels and 1200 vertical pixels. At a resolution of 1600 x 1200 , all pixels are displayed as a full screen. Temperature Color Temperature is a method to measure the white color tone, generally indicated in degrees Kelvin.

  • Page 35: Appendix/Anhang/Annexe

    6. APPENDIX/ANHANG/ANNEXE . APPENDIX/ANHANG/ANNEXE Preset Timing Chart for Analog input Timing-Übersichten für Analog Eingang Synchronisation des Signaux pour Analog numerique NOTE • Based on the signal diagram shown below factory presets have been registered in the monitor's microprocessor. • Der integrierte Mikroprozessor des Monitors unterstützt werkseitige Standardeinstellungen (siehe hierzu die nachfolgenden Diagramme).

  • Page 36: About Tco'03

    Congratulations! The display you have just purchased carries the TCO’03 Displays label. This means that your display is designed, manufactured and tested according to some of the strictest quality and environmental requirements in the world. This makes for a high performance product, designed with the user in focus that also minimizes the Impact on our natural environment.

  • Page 37: Fcc Declaration Of Conformity

    Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord...

  • Page 38: Hinweise Zur Auswahl Des Richtigen

    Hinweise zur Auswahl des richtigen Schwenkarms für Ihren Monitor Dieser Monitor ist für Bildschirmarbeitsplätze vorgesehen. Wenn nicht der zum Standardzubehör gehörige Schwenkarm verwendet wird, muss statt dessen ein geeigneter anderer Schwenkarm installiert werden. Bei der Auswahl des Schwenkarms sind die nachstehenden Hinweise zu berücksichtigen: Der Standfuß muß den nachfolgenden Anforderungen entsprechen: a) D er Standfuß muß eine ausreichende mechanische Stabilität zur Aufnahme des Gewichtes vom Bildschirmgerät und des spezifizierten Zubehörs besitzen. Das Gewicht des Bildschirmgerätes und des Zubehörs sind in der zugehörenden Bedienungsanleitung angegeben. b) D ie Befestigung des Standfusses muß derart erfolgen, daß die oberste Zeile der Bildschirmanzeige nicht höher als die Augenhöhe eines Benutzers in sitzender Position ist. c) I m Fall eines stehenden Benutzers muß die Befestigung des Bildschirmgerätes derart erfolgen, daß die Höhe der Bildschirmmitte über dem Boden zwischen 135 – 150 cm beträgt. d) D er Standfuß muß die Möglichkeit zur Neigung des Bildschirmgerätes besitzen (max. vorwärts: 5°, min. nach hinten ≥...
