SPECIFICATIONS

RELIEF VALVE SETTINGS

Relief Valve
Hoist, Telescope & Boom Circuits
Swing Circuit
Outrigger Circuit
Steering Circuit

GENERAL SPECIFICATIONS

Engine

Diesel
Make and model ............................................................................................... Cummins 4B3.3-85 diesel. Tier II
Type of Aspiration ............................................................................................. Turbocharged
Horsepower ...................................................................................................... 85 hp @ 2500 rpm
Low idle speed .................................................................................................. 800 rpm
Maximum engine speed .................................................................................... 2600 rpm
Gasoline/L.P.G.
Make and model ............................................................................................... GMC 4.3 L EFI V6, US ZEPA & CARB 2004
.......................................................................................................................... certified
Horsepower ...................................................................................................... 110 hp @ 2500 rpm
Low idle speed .................................................................................................. 700 rpm
Maximum engine speed .................................................................................... 2600 rpm

Tires

Size ................................................................................................................... 385/65R22.5
Type .................................................................................................................. Radial
Air pressure....................................................................................................... 120 psi (828 kPa)
Wheel nut torque............................................................................................... 500 lb-ft. (680 Nm)

Electrical System

Rating ............................................................................................................... 12 VDC negative ground
Number and type of batteries:
Standard ........................................................................................................... One-maintenance free
With optional cold weather start ........................................................................ Two
Battery rating..................................................................................................... 90 amp/hr
Alternator .......................................................................................................... 63 amps

Boom

Reach (from center line of rotation)
3 Section Boom................................................................................................. 41' 0" (12.50 m)
8-4
3500 ± 50 psi (241 ± 3.5 bar)
3000 ± 50psi (138 ± 3.5 bar)
3000 ± 50psi (241 ± 3.5 bar)
2500 ± 50psi (172 ± 3.5 bar)
Published 10-21-2011, Control # 055-03
5540F/YB5515 OPERATOR'S MANUAL
Pressure Setting
