MAINTENANCE
p0421
Steering Knuckle Lube Points (Rear Axle)
p0419
Steering Link Lube Points (Front Axle)
p0422
Steering Link Lube Points (Rear Axle)
6-8
p0418
Steering Cylinder Pivot Ends Lube Points (Front Axle)
FIGURE 6-7
p0420
FIGURE 6-8
Steering Cylinder Pivots Ends Lube Points (Rear Axle)
FIGURE 6-9
Published 10-21-2011, Control # 055-03
5540F/YB5515 OPERATOR'S MANUAL
FIGURE 6-10
FIGURE 6-11
