GENERAL INFORMATION

The Seametrics TempHion™
microprocessor-based submersible sensor with built-in
data logging, storing thousands of records in non-volatile
memory. The pH/ORP version measures pH, ORP (Redox),
and temperature. The ISE version measures bromide and
temperature.
The internal processor in the TempHion allows for easy
calibration, using the calibration utilities in Aqua4Plus.
Once calibrated, this calibration data is stored in non-
volatile memory within the Smart Sensor. When data is
collected, this calibration information is applied to the
data, resulting in highly accurate readings at a wide range
of temperatures.
The TempHion is powered internally with two replaceable
AA batteries. Alternately it can be powered with an external
auxiliary power supply for data intensive applications.
The unit is programmed using Seametrics' easy-to-use
Aqua4Plus control software. Once programmed the unit
will measure and collect data on a variety of time intervals.

Dimensions

0.28" (0.7 cm)
Cableless
0.25" (0.6 cm)
Shorter
0.28" (0.7 cm)
Non-batttery versions are 3.8" (9.65 cm) shorter.
Seametrics • 253.872.0284
Smart Sensor is
17.96" (45.6 cm)
pH/ORP Version
17.96" (45.6 cm)
ISE Version
Page 4
a Several TempHions, or a combination of TempHions
and other Seametrics Smart Sensors, can be networked
together and controlled from one location directly from a
single computer.
While most will use the TempHion with our free, easy-to-
use Aqua4Plus software, it is by no means limited to that
software. You can use your own Modbus
software or logging equipment to read measurements,
thus tying into your existing systems and data bases.
pH/ORP element
ISE element
TEMPHION INSTRUCTIONS
RTU or SDI-12
®
Reference Reservoir
seametrics.com
Diameter
0.75" (1.9 cm)
