GENERAL INFORMATION

The INW CT2X Smart Sensor is a microprocessor-based
submersible conductivity/temperature sensor with built-
in data logging. This device stores thousands of records
of conductivity, temperature, salinity, and total dissolved
solids (TDS). The CT2X is also available with a depth/level
option giving added functionality in the same sensor
housing.
The CT2X incorporates 4-pole electrode cell measurement
technology for conductivity, salinity, and TDS.
technology reduces fringe field interference errors,
lessens inaccuracy caused by polarization effects, and
lowers contact resistance problems. Four-pole electrode
technology also allows users to work with one electrode
over a wide range of conductivity. The conductivity element
is constructed of epoxy/graphite, making it extremely
durable for use in rugged field conditions. To clean, simply
scrub with a small brush.
Depth and level is measured with an extremely rugged
and stable piezo-electric, media isolated pressure element
and compensated for temperature using INW's proprietary

Dimensions

Cableless
0.25" (0.6 cm)
Shorter
Seametrics • 253.872.0284
Battery Version
0.28" (0.7 cm)
Non-Battery Version
0.28" (0.7 cm)
calibration methodology. Temperature is measured using a
borosilicate glass encapsulated thermistor.
The CT2X is powered internally with two AA batteries.
Alternately it can be powered with an external auxiliary
power supply for data intensive applications.
CT2Xs, or a combination of CT2Xs and other INW Smart
Sensors, can be networked together and controlled from
one location, either directly from a single computer or via
This INW's Wireless Data Collection System.
While most will use the CT2X with our free, easy-to-use
Aqua4Plus Lite or Aqua4Plus software, it is by no means
limited to that software. You can use your own Modbus®
RTU or SDI-12 software or logging equipment to read
measurements, thus tying into your existing systems and
data bases.
15.44" (39.2 cm)
11.64" (29.6 cm)
with Pressure:
1.5" (3.8 cm)
Longer
Page 4
CT2X INSTRUCTIONS
Several
Diameter
0.75" (1.9 cm)
