GENERAL INFORMATION

The Seametrics PT2X Smart Sensor is an integrated data
logger and pressure/temperature sensor and is ideal for
monitoring groundwater, well, tank, and tidal levels, as well
as for pump and slug testing. This sensor networks with
all of the Seametrics Smart Sensor family. IThe PT2X is a
microprocessor based digital intelligent sensor designed
to measure and record pressure, temperature, and time,
using low power, battery operated circuitry.
Pressure is measured with an extremely rugged and stable
piezo-electric media-isolated pressure element combined
with a 16-bit analog-to-digital converter. This provides
extremely accurate and stable pressure input into the
microprocessor on the circuit board.
This industry standard digital RS485 interface device records
up to 520,000 records of pressure/level, temperature, and
time data, operates with low power, and features easy-to-
use software with powerful features. Constructed with 316
stainless steel or titanium, PTFE, and fluoropolymer, this
sensor provides high-accuracy readings in rugged and
corrosive field conditions.

Dimensions

Cableless
0.25" (0.6
cm) Shorter
Seametrics • 253.872.0284
Battery Version
0.28" (0.7 cm)
8.37" (21.3 cm)
Non-Battery Version
0.28" (0.7 cm)
Page 3
Two internal 1.5V AA batteries power the PT2X. (Auxiliary
power supplies are available for data intensive applications.)
The unit is programmed using Seametrics' easy-to-use
Aqua4plus 2.0 control software. Once programmed the
unit will measure and collect data on a variety of time
intervals.
Several PT2Xs, or a combination of PT2Xs and other
Seametrics Smart Sensors, can be networked together and
controlled directly from a single computer.
While most will use the PT2X with our free, easy-to-use
Aqua4Plus 2.0 software, it is by no means limited to that
software. You can use your own Modbus
software or logging equipment to read measurements,
thus tying into your existing systems and databases.
12.18" (30.9 cm)
PT2X INSTRUCTIONS
RTU or SDI-12
®
Diameter
0.75" (1.9 cm)
