- Page 1 Assembly Instructions Please keep for future reference. AquaSys ReefSys 150cm Cabinet Suitable for AquaSys 395 or ReefSys 434 Aquariums Version 1 - 25/11/19 Important - Please read these instructions fully before starting assembly...
-
Page 2: Care And Maintenance
Safety Care and Advice IMPORTANT: Please read these instructions before starting assembly • Warning: This unit is heavy. • Make sure you have enough space • We do not Please lift with care. to layout the parts before starting. recommend the use of power drill/ •... - Page 3 Panels Please check you have all the panels listed below. 2x Side panels 2 x Wide back brace 764 x 530mm 764 x 200mm 1x Base 1x Top 1504 x 531mm 1504 x 531mm 1x Narrow front brace 3x Door 764x100mm 786 x 496mm 2x Back brace...
- Page 4 Fittings Please check you have all the fittings listed below. 40x 15mm Large 40x Cam Bolts 6x Hinges Locking Cam Nut 6x Hinge Plates 8x Hammer-in Glides 18x 3.5x15mm Screws 3x Push Catch 1x Aperture Trim Ring 4x Short Cam Bolts...
- Page 5 Step One Lay side panels (A) on the floor with holes facing upwards. Fit 6x Cam fittings (1) into larger holes with cross facing up and the arrow facing the edge of the board. Screw 3x Cam Bolts (2) into the 5mm holes along the back edge.
- Page 6 Step Two Fit Cam Fittings (1) into the 7 holes of the Wide Back Braces (B) and into the four holes into back braces (G). Attach the raw edge of the Wide Back Braces to the back edge of the sides giving the Cam Fittings a half turn with the screwdriver.
- Page 7 Step Three Fit 6 Cam Fittings (1) into larger holes on divider (H) with cross facing up and the arrow facing the edge of the board. Attach the two hinge plates (4) to the side of divider (H) that has the two pairs of 5mm holes at the front edge with the flat edge at the front.
- Page 8 Step Four Using a hammer, fit glides (5) to the underside of the base panel (C) using the pip marks as a guide for fitment then turn the base over to have the 5mm holes facing upwards. Screw in cam bolts (2) into all of the 5mm holes with the exception of the two on the front edge which should have short Cam Bolts (9).
- Page 9 Step Five Drop sides with attached back braces onto the cams on the base. Similarly attach the back braces (G) to the centre of the base at the back. Drop divider (H) into position on the Cam Bolts with Hinge Plates on the right hand face. Give all cam fittings a half turn with the screwdriver.
- Page 10 Step Six Lay top panel (D) with holes facing upwards, screw cam bolts (2) into all 5mm holes with exception of the 2 holes at the front edge next to the pip marks which should have the remaining 2 short cam bolts (9) fitted. Using 4 of screws (6) attach the brackets for the push catches (7) with the arrows facing forwards, to the pip marks then attach the push catch to the bracket by clipping in at the back and pushing down at the front until you hear a click.
- Page 11 Step Six Continued...
- Page 12 Step Seven From the inside of the cabinet push aperture trim ring (8) through the hole in the top of the cabinet. We highly recommenced securing with silicone to seal the edge and protect the chipboard.
- Page 13 Step Eight Clip narrow front brace (F) over the short cam bolts and tighten in a similar manner to all the others.
- Page 14 Step Nine Lay doors (E) on floor with the hinge holes facing up, place hinges (3) into holes and screw in using remaining screws (6). Hook hinge arms into the front of the hinge plate and push in at the back of the arm until they click.
