- Page 1 Assembly Instructions Please keep for future reference Inspire 40 Version 1 : 21/07/2020 Important - Please read these instructions fully before starting assembly ALR3662...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 11kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 Panels & Fittings Please check you have all the panels and fittings listed below Base (D2472_01) (D2475_01) (400 x 398mm) (326 x 377mm) Rail (D2476_01) Left Side Right Side (D2505_01) (D2506_01) (715 x 396mm) (715 x 396mm) (326 x 57mm) Door (DF-00020960) (646 x 322mm)
- Page 4 Step 1 Prepare the Left Side Screw 6 Large Metal Dowels into the Left Side. Push 2 Hollow Core Locking Nuts into the Left Side, making sure that they are flush against the panel’s surface. Using a hammer, tap in the pin on the Hollow Core Locking Nut.
- Page 5 Step 3 Prepare the Top Finished front edge Screw 4 Small Metal Dowels into the Top. Step 4 Join the top to the Left Side Slide the Small Metal Dowels fitted to the Top into the Hollow Core Locking Nuts fitted to the Left Side.
- Page 6 Step 6 Fit the Base to the Left Side Finished front edge Push the Base down onto the Left Side. Use a screwdriver to tighten the 2 Large Locking Nuts fitted to the Base. Note: Turn the Large Locking Nuts as far as they will go - more than 1/2 a turn.
- Page 7 Step 9 Fit the Right Side Push the Right Side down onto the assembly. Use a screwdriver to tighten the 6 Large Locking Nuts fitted to the Base and Rails. Insert a screwdriver into the 2 Hollow Core Locking Nuts and turn the nuts inside as far as they will go.
- Page 8 Step 12 Fit the Door and Handle We recommend that you fit the top Hinge first, then align and fit the other Hinge. Push the Hinge onto the front part of the Hinge Plate. The recess at the bottom of Screw B goes into the slot in the Hinge Plate.
- Page 9 Step 13 Adjust the Door if required Before adjusting the Door, use a spirit level to check the Top (or Base) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the...
