- Page 1 Assembly Instructions Please keep for future reference Oakstyle 145 Version 2 : 09/10/2017 Important - Please read these instructions fully before starting assembly ALR3414...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit is heavy. • Make sure you have enough • We do not Please lift with care. space to layout the parts before recommend the starting. - Page 3 Panels Please check you have all the panels listed below 1 Left Drawer 2 Right Drawer 3 Left Drawer 4 Right Drawer Front Front Side Side (DF-00011548) (DF-00011549) (W330-124LH) (W330-124RH) (34.2 x 16.2cm) (34.2 x 16.2cm) (33 x 12.4cm) (33 x 12.4cm) 5 Drawer Back (W303-124) (30.3 x 12.4cm)
- Page 4 Fittings Please check you have all the fittings listed below Small Locking Cam Knock-in Peg Large Metal Dowel x 20 (F901) (F900) (F171GY) Large Locking Cam Wooden Dowel x 20 (F22) Wedgefix x 22 (F639) (F900) Door Buffer 45mm Screw 19mm Screw ( (F137) (F65)
- Page 5 Step 1 Shallow I.D. hole Prepare the 2 Drawer Fronts Screw 2 Metal Dowels into each of the Drawer Fronts. Note: Tighten the Metal Dowels up fully against the panels. Stick 2 Door Buffers into the corners of each Drawer Front, as shown. Step 2 Prepare the Drawer Sides...
- Page 6 Step 4 Fit the Drawer Bases Slide the Drawer Bases down the grooves in the Drawer Sides and down into the groove in the Drawer Fronts. Step 5 Fit the Drawer Back Fit the Drawer Backs between the Drawer Sides. Make sure that the Drawer Base fits into the groove in the Drawer...
- Page 7 Step 8 Left Fascia - holes Prepare the 2 Fascias nearest this side 10mm Check that the holes are in the same place as the diagrams, as one will be the Left Fascia and one will be the Right Fascia. Tap a Wooden Dowel into each of the 2 Fascias.
- Page 8 Step 10 Fit the Left Fascia to the Left Side Push the Left Side down onto the Left Fascia. Dowel this end Use a screwdriver to tighten the 3 Large Locking Cam Nuts fitted to the Left Side. Note: Turn the Large Locking Cam Nuts as far as they will go - more than 1/2 a turn.
- Page 9 Step 12 Prepare the Right Side Tap 2 Wooden Dowels into the Right Side. Insert 5 Large Locking Cam Nuts into the Right Side. Push 3 of the Quickfit Dowels as far as they will go into the Right Side. Step 13 Fit the Right Fascia to the Right Side...
- Page 10 Step 14 Finish preparing the Right Side Place a runner on the Right Side as shown. Slide back the top of Runner and use the 2nd hole from the front to fit the first 9mm Screw. Slide the Runner back the other way and fit the second 9mm Screw into the corresponding hole in the...
- Page 11 Step 17 Prepare the 2 Plinths Tap 2 Wooden Dowels into each of the Plinths. Insert 2 Large Locking Cam Nuts into each of the Plinths. Step 18 Fit the Plinths Push the 2 Plinths onto the Right Side. Use a screwdriver to tighten the Large Locking Cam Nut fitted to each Plinth.
- Page 12 Step 20 Prepare the Divider Place a Runner on the Divider as shown. Slide back the top of Runner and use the 2nd hole from the front to fit the first 9mm Screw. Slide the Runner back the other way and fit the second 9mm Screw into the corresponding hole in the...
- Page 13 Step 21 Fit the Divider Push the Divider onto the Base and secure it with 2 40mm Screws. Step 22 Packaging piece Packaging Raise the assembly piece To make it easier to fit the Top Panel, place packaging pieces underneath the Side Panels and Divider to raise the assembly.
- Page 14 Step 24 Fit the Top Push the Top onto the assembly. Use a screwdriver to tighten the 6 Large Locking Cam Nuts fitted to the Divider and the Sides. Step 25 Prepare the Back Tap 2 Wooden Dowels into the Back. Insert 2 Large Locking Cam Nuts into the Back.
- Page 15 Step 27 Fit the Plastic Nails Tap 2 Plastic Nails into the bottom edge of each of the Sides. Tap a Plastic Nail into the centre of the bottom edge of the 2 Plinths and the Back. Step 28 This unit must be fixed to a wall using the 2 Overbalance Protector Kits provided Secure the unit to a wall...
- Page 16 Step 29 Fit the Shelf The Shelf can be fitted to either side of the unit. Insert 4 Shelf Studs, at the required height. Lower the Shelf down onto the Shelf Studs. The 6 Shelf Studs you have left are required for Hood fixing.
- Page 17 Step 32 Fit the Doors and its Handles Line up the 2 screws in the top Hinge with the 2 holes at the top of the Sides and push them in. Press the Screws into When the Hinges have the holes in the panels been pushed in, Now push in the other tighten up their Screws...
- Page 18 Step 34 Fit the Door Buffers Stick a Door Buffer onto the bottom corner of each Door where they will hit the Base.
