Assembly Instructions
Please keep for future reference
Shades 1+1 Cabinet
Version 1 : 07/12/2018
Important -
Please read these instructions fully before starting assembly
ALR3507

Advertisement

loading
Need help?

Need help?

Do you have a question about the Shades 1+1 Cabinet and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Aqua One Shades 1+1 Cabinet

  • Page 1 Assembly Instructions Please keep for future reference Shades 1+1 Cabinet Version 1 : 07/12/2018 Important - Please read these instructions fully before starting assembly ALR3507...
  • Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit is heavy. • Make sure you have enough • We do not Please lift with care. space to layout the parts before recommend the starting.
  • Page 3 Panels Please check you have all the panels listed below 1 Drawer Front 2 Left Drawer 3 Right Drawer Side Side (DF-00015635) (W300-124LH) (W300-124RH) (36.2 x 15.7cm) (30 x 12.4cm) (30 x 12.4cm) 4 Drawer Back 5 Drawer Base (W326-124) (T337-297) (32.6 x 12.4cm) (33.7 x 29.7cm)
  • Page 4 Fittings Please check you have all the fittings listed below Bag 1 Large Locking Cam Large Metal Dowel x 26 Wooden Dowel x 26 (F901) (F22) x 26 (F900) 45mm Screw Door Stop 9mm Screw ( (F65) (F464) F73) Shelf stud (F110) 13mm Screw (F79)
  • Page 5 Use Bag 2 for steps 1 - 7 Step 1 Prepare the Drawer Front Screw 2 Metal Dowels into the Drawer Front. Note: Tighten the Metal Dowels up fully against the panel. Step 2 Prepare the Drawer Sides Insert a Small Locking Cam Nut into the Left Drawer Side and the Right Drawer Side.
  • Page 6 Step 4 Fit the Drawer Base Slide the Drawer Base down the grooves in the Drawer Sides and down into the groove in the Drawer Front. Step 5 Fit the Drawer Back Fit the Drawer Back between the Drawer Sides. Make sure that the Drawer Base fits into the groove in the Drawer...
  • Page 7 Use Bag 1 for steps 8 - end Step 8 Prepare the Left Side 10mm Tap 6 Dowels into the Left Side. Note: Wooden Dowels must not stick out from the edge by more than 10mm or they may damage other panels. Insert 8 Large Locking Cam Nuts into the Left Side.
  • Page 8 Step 11 Fit the Legs to the Left Side Push the 2 Legs onto the Left Side. Use a screwdriver to tighten the 6 Large Locking Cam Nuts fitted to the Left Side. Note: Turn the Locking Cam Nuts as far as they will go - more than 1/2 a turn.
  • Page 9 Step 13 10mm Prepare the Right Side Tap 6 Dowels into the Right Side. Note: Wooden Dowels must not stick out from the edge by more than 10mm or they may damage other panels. Insert 8 Large Locking Cam Nuts into the Right Side.
  • Page 10 Step 16 Fit the Legs to the Right Side Push the 2 Legs onto the Right Side. Use a screwdriver to tighten the 6 Large Locking Cam Nuts fitted to the Right Side. Note: Turn the Locking Cam Nuts as far as they will go - more than 1/2 a turn.
  • Page 11 Step 18 Finished Front Edge Prepare the Rail Fit the Bracket to the mark-hole in the Rail using a 13mm Screw. Rail Insert 2 Locking Cam Nuts into the Rail. Step 8 Step 19 Fit the Rail to the Right Side Push the Rail onto the Right Side.
  • Page 12 Step 21 Fit the Base to the Right Side Push the Base onto the Right Side. Use a screwdriver to tighten the 2 Large Locking Cam Nuts fitted to the Base. Finished Secure the Bracket on Front Edge the Rail to the mark-hole in the Base using a 13mm Screw.
  • Page 13 Step 24 Fit the Left Side Push the Left Side onto the assembly. Use a screwdriver to tighten the 4 Large Locking Cam Nuts fitted to the Base, Rail and Support Rail. Step 8 Step 25 Prepare the Top Fit the 2 Brackets from the Overbalance Protector Kits to the shallow mark-holes...
  • Page 14 Step 26 Fit the Top To make the fitting of the Top easier, raise the assembly as shown. Push the Top onto the assembly. Use a screwdriver to tighten the 4 Locking Cam Nuts fitted to the Sides. Raise the Sides using packaging, wood, books etc.
  • Page 15 This unit must be fixed to a wall using the Step 29 2 Overbalance Protector Kits provided Secure the unit to a wall Before fitting the unit to a wall, use a Spirit Level to check the Top of the unit is level, front-to-back and side-to-side in the 3 positions shown.
  • Page 16 Step 30 The Runners could have sharp edges and Fit the Drawer we recommend that you position them Slide both the Runners using a Screwdriver. forward and locate the Drawer Sides between them, lining up their holes with the 2nd 'threaded' holes in the Runners.
  • Page 17 Step 32 Fit the Door NOTE: The Door can be fitted to either side. Line up the 2 screws in When the Hinges have the top Hinge with the 2 been pushed in, Press the Screws into holes at the top of the tighten up their Screws the holes in the panels Sides and push them in.
  • Page 18 Step 33 DO NOT USE the Screw supplied with the Handle Fit the Handle Attach a Handle to the Door using a 19mm Screw.
  • Page 19 Step 34 Adjust the Door if needed Height adjustment. Loosen Screws A on Hinge Plates and move Door up or down as required. Retighten Screw A. Forward and Back adjustment. Loosen Screw B on Hinge Plate and move Door in or out as required.
  • Page 20 Step 35 Fit the Door Stop Screw the Door Stop into the Leg, as shown. The position of the Door can be adjusted by turning the Door Stop clockwise or anti-clockwise. Assembly is complete...
