- Page 1 Assembly Instructions Please keep for future reference OakStyle Urban 110 Version 1 : 30/10/2019 Important - Please read these instructions fully before starting assembly ALR3625...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit is heavy. • Make sure you have enough • We do not Please lift with care. space to layout the parts before recommend the starting.
- Page 3 Panels Please check you have all the panels listed below 1 Drawer Front 2 Left Drawer Right Drawer Side Side (DF-00020355) (WRP-00000052) (WRP-00000053) (68.6 x 16cm) (35 x 12.4cm) (35 x 12.4cm) 4 Drawer Back (WRP-00000375) (62.95 x 12.4cm) 5 Drawer Base (TDF-00020373) (64.05 x 34.7cm) 6 Left Side...
- Page 4 Fittings Please check you have all the fittings listed below Bag 1 Large Locking Cam Large Metal Dowel x 10 Wooden Dowel x 14 (F901) (F22) x 10 (F900) Allen Key 50mm Screw 40mm Screw (F36) (F49) (F910) 45mm Screw 13mm Screw x 14 9mm Screw (...
- Page 5 Use Bag 2 for steps 1 - 7 Step 1 Prepare the Drawer Front Screw 2 Metal Dowels into the Drawer Front. Note: Tighten the Metal Dowels up fully against the panel. Stick a door buffer Note: The Door Buffers into the top corners of can be found in Bag 1 the Drawer Front.
- Page 6 Step 4 Fit the Drawer Base Slide the Drawer Base down the grooves in the Drawer Sides and down into the groove in the Drawer Front. Step 5 Fit the Drawer Back Fit the Drawer Back between the Drawer Sides. Make sure that the Drawer Base fits into the groove in the Drawer...
- Page 7 Use Bag 1 for steps 8 - end Step 8 Prepare the 2 H-Frame Uprights Finished Screw 2 Metal Dowels front edge into the H-Frame LH Upright and the H-Frame RH Upright. Finished front edge Step 8 Step 9 Prepare the 2 H-Frame Cross Rails Tap 2 Wooden Dowels into the H-Frame Cross...
-
Page 8: Table Of Contents
Step 11 Fit the H-Frame RH Upright Push the H-Frame RH Upright onto the 2 H-Frame Cross Rails. Use a flat-head screwdriver to tighten the Finished 2 Large Locking Cam front edge Nuts fitted to the 2 H-Frame Cross Rails. Step 8 Step 12 Add the Base... - Page 9 Step 13 Prepare the Left Side Place a runner on the Left Side, as shown. Slide back the top of Runner and use the 2nd hole from the front to fit the first 9mm Screw. Slide the Runner back the other way and fit the second 9mm Screw into the corresponding hole in the...
- Page 10 Step 14 Prepare the Right Side Place a runner on the Right Side, as shown. Slide back the top of Runner and use the 2nd hole from the front to fit the first 9mm Screw. Slide the Runner back the other way and fit the second 9mm Screw into the corresponding hole in the...
- Page 11 Step 15 Fit the Right Side to the Base Attach the Right Side to the Base using two 40mm Screws. Finished front edge Finished front edge Step 16 Fit the Left Side Attach the Left Side to the Base using two 40mm Screws.
-
Page 12: Screwdriver To Tighten The 2 Large Locking Cam
Packaging Step 18 piece Raise the assembly To make it easier to fit Packaging the Top Panel, place piece packaging pieces underneath the Side Panels to raise the assembly. Packaging piece Packaging piece Step 19 Packaging piece Fit the Top Push the Top Panel onto the 2 Side Panels. - Page 13 Step 21 Prepare the Back Tap 2 Wooden Dowels into the Back. Insert 2 Large Locking Cam Nuts into the Back. Step 22 Fit the Back Push the Back onto the Top. Use a screwdriver to tighten the 2 Large Locking Cam Nuts fitted to the Back.
- Page 14 Step 23 This unit must be fixed to a wall using Secure the unit to a the Overbalance Protector Kit provided wall Before fitting the unit to a wall, use a spirit level to check the top of the unit is level, front-to-back and side-to-side in the 3 positions shown.
-
Page 15: Finished
Step 24 Fit the Shelf Push in 4 Shelf Supports at the required height. Important: The prong of the Shelf Supports must be pointing upwards. Position the holes in the Shelf over the Shelf Supports and push them down onto the prongs. Finished front edge Step 8... - Page 16 Step 26 When the hinges have Press the screws into been pushed in, Fit the Doors the holes in the panels tighten up their screws Line up the 2 screws in the top Hinge with the 2 holes at the top of the Side and push them in.
- Page 17 Step Fit the Door Buffers Stick a door buffer onto the bottom corner of each Door. Step 29 Fit the Drawer Slide both the Runners forward and locate the Drawer Sides between 2nd threaded them, lining up their hole holes with the 2nd 'threaded' holes in the Runners.
- Page 18 Step 30 Adjust the Doors if needed Height adjustment. Loosen Screws A on Hinge Plates and move Door up or down as required. Retighten Screw A. Forward and Back adjustment. Loosen Screw B on Hinge Plate and move Door in or out as required.
