- Page 1 Assembly Instructions Please keep for future reference. AquaSys ReefSys 90/120cm Cabinet Suitable for AquaSys 230/300 or ReefSys 255/326 Aquariums Version 1 - 25/11/19 Important - Please read these instructions fully before starting assembly...
-
Page 2: Care And Maintenance
Safety Care and Advice IMPORTANT: Please read these instructions before starting assembly • Warning: This unit is heavy. • Make sure you have enough space • We do not Please lift with care. to layout the parts before starting. recommend the use of power drill/ •... - Page 3 Panels Please check you have all the panels listed below. 2x Side panels 2 x Wide back brace 764 x 530mm 764 x 200mm 1x Base 1x Top 900mm Cabinet: 904 x 531mm 900mm Cabinet: 904 x 531mm 1200mm Cabinet 1204 x 531mm 1200mm Cabinet 1204 x 531mm 1x Back brace 1x Narrow front brace...
- Page 4 Fittings Please check you have all the fittings listed below. 30x 15mm Large 30x Cam Bolts 4x Hinges Locking Cam Nut 4x Hinge Plates 6x Hammer-in Glides 12x 3.5x15mm Screws 2x Push Catch 1x Aperture Trim Ring 4x Short Cam Bolts...
- Page 5 Step One Lay side panels (A) on the floor with holes facing upwards. Fit 6x Cam fittings (1) into larger holes with cross facing up and the arrow facing the edge of the board. Screw 3x Cam Bolts (2) into the 5mm holes along the back edge.
- Page 6 Step Two Fit Cam Fittings (1) into the 7 holes of the Wide Back Braces (B). Repeat for both back braces. Fit Cam Fittings (1) into the 4 holes of the back brace (G). Attach the raw edge of the Wide Back Braces (B) to the back edge of the sides giving the Cam Fittings a half turn...
- Page 7 Step Three Using a hammer, fit glides (5) to the underside of the base panel (C) using the pip marks as a guide for fitment then turn the base over to have the 5mm holes facing upwards. Screw in cam bolts (2) into all of the 5mm holes, with the exception of the two on the front edge which should have short cam bolts (9).
- Page 8 Step Four Drop sides with attached back braces onto the cams on the base. Similarly attach the back brace (G) to the centre of the base at the back. Give all cam fittings a half turn with the screwdriver.
- Page 9 Step Five Lay top panel (D) with holes facing upwards, screw cam bolts (2) into all 5mm holes with exception of the 2 holes at the front edge next to the pip marks which should have the remaining 2 short cam bolts (9) fitted. Using 4 of screws (6) attach the brackets for the push catches (7) with the arrows facing forwards, to the pip marks then attach the push catch to the bracket by clipping in at the back and pushing down at the front until you hear a click.
- Page 10 Step Five Continued...
- Page 11 Step Six From the inside of the cabinet push aperture trim ring (8) through the hole in the top of the cabinet. We highly recommenced securing with silicone to seal the edge and protect the chipboard.
- Page 12 Step Seven Clip narrow front brace (F) over the short cam bolts and tighten in a similar manner to all the others. PLEASE NOTE: Brace (F) can be removed from assembled cabinet, to allow fitment of equipment to interior of cabinet. But must be fitted before tank is placed on top.
- Page 13 Step Eight Lay doors (E) on floor with the hinge holes facing up, place hinges (3) into holes and screw in using remaining screws (6). Ensuring the label with the arrow points to the top, hook hinge arms into the front of the hinge plate and push in at the back of the arm until they click.
