Assembly Instructions
Please keep for future reference
Styleline 51
Version 1 : 03/08/2017
Important -
Please read these instructions fully before starting assembly
ALR3418

Advertisement

loading
Need help?

Need help?

Do you have a question about the Styleline 51 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Aqua One Styleline 51

  • Page 1 Assembly Instructions Please keep for future reference Styleline 51 Version 1 : 03/08/2017 Important - Please read these instructions fully before starting assembly ALR3418...
  • Page 2: Care And Maintenance

    Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit is heavy. • Make sure you have enough • We do not Please lift with care. space to layout the parts before recommend the starting.
  • Page 3 Panels Please check you have all the panels listed below 3 Top (DF-00012321) (50.8 x 30.3cm) 1 Left Side 2 Right Side 4 Base (DF-00012322) (DF-00012323) (DF-00012324) (74.7 x 29.3cm) (74.7 x 29.3cm) (45.8 x 25.5cm) 5 Shelf 6 Plinth 7 Top Rail (DF-00012326) (DF-00012328)
  • Page 4 Fittings Please check you have all the fittings listed below Large Locking Cam Large Metal Dowel x 12 Wooden Dowel x 16 (F901) (F22) x 12 (F900) 45mm Screw 19mm Screw ( 13mm Screw (F65) F461) (F63) Hinge Plate Plastic Nail (F91) Hinge (F522)
  • Page 5 Step 1 10mm Prepare the Left Side Tap 2 Wooden Dowels into the Left Side. Insert 2 Large Locking Cam Nuts into the Left Finished Side. Front Edge Screw 3 Metal Dowels into the Left Side. Fit 2 hinge plates onto the Left Side, making sure that the slot is facing towards the...
  • Page 6 Step 4 Fit the Base to the Right Side Push the Base onto the Right Side. Use a screwdriver to tighten the 2 Large Locking Cam Nuts Finished fitted to the Base. Front Edge Note: Turn the Large Locking Cam Nuts as far as they will go - more Finished than 1/2 a turn.
  • Page 7 Step 7 Prepare the Plinth Tap 4 Wooden Dowels into the Plinth. Step 8 Fit the Plinth Push the Plinth onto the Right Side. Step 9 Fit the Left Side Push the Left Side onto the assembly. Use a screwdriver to tighten the 3 Large Locking Cam Nuts fitted to the Base and...
  • Page 8 Step 10 Prepare the top Screw 6 Metal Dowels into the Top. Fit the 2 Brackets from the Overbalance Protector Kits to the shallow mark-holes drilled into the Top using 1 of their Screws. Note: Only fit 1 of the Screws, the other 1 will be fitted later.
  • Page 9 Step 13 Prepare the Back Tap 2 Wooden Dowels into the Back. Insert 2 Large Locking Cam Nuts into the Back. Step 14 Fit the Back Push the Back onto the Top. Use a screwdriver to tighten the 2 Large Locking Cam Nuts fitted to the Back.
  • Page 10 Step 16 This unit must be fixed to a wall using the Secure the unit to a 2 Overbalance Protector Kits provided wall Before fitting the unit to a wall, use a spirit level to check the top of the unit is level, front-to-back and side-to-side in the 3 positions shown.
  • Page 11 Step 17 Fit the Shelf Studs Insert 4 Shelf Studs for each of the 2 Shelves, at the required height. Step 18 Fit the 2 Shelves Lower the Narrow Shelves down onto the Shelf Studs. Step 19 Prepare the Door Push fit the 2 Hinges into the Door and secure them using the 13mm...
  • Page 12 Step 20 Fit the Door and Handle Note: The easiest way to attach the Door is to fit the top Hinge first, then align and fit the other Hinge. Push the Hinge onto the front part of the Hinge Plate. The recess at the bottom of screw B goes into the slot in the Hinge Plate.
  • Page 13 Step 21 Adjust the Door if needed Before adjusting the Door, use a spirit level to check the Top (or Base) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the...
