Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit is heavy. • Make sure you have enough • We do not Please lift with care. space to layout the parts before recommend the starting.
Page 3
Panels Please check you have all the panels listed below 1 Left Drawer 2 Right Drawer 3 Left Drawer 4 Right Drawer Side Side Front Front (W300-124LH) (W300-124RH) (DF-00014971) (DF-00014972) (30 x 12.4cm) (30 x 12.4cm) (36.2 x 15.7cm) (36.2 x 15.7cm) 5 Drawer Back 6 Drawer Base (W326-124)
Page 4
Fittings Please check you have all the fittings listed below Small Locking Cam Knock-in Peg Large Metal Dowel x 32 (F901) (F900) (F171GY) Large Locking Cam Wooden Dowel x 30 (F22) Wedgefix x 28 (F639) (F900) 40mm Screw 45mm Screw 19mm Screw (F910) (F65)
Page 5
Step 1 Shallow I.D. hole Prepare the Left and Right Drawer Fronts Screw 2 Metal Dowels into the Left and Right Drawer Fronts. Note: Tighten the Metal Dowels up fully against the panels. Step 2 Prepare the 2 sets of Drawer Sides Insert a Small Locking Cam Nut into the 2 Left...
Page 6
Step 4 Fit the Drawer Bases Slide the Drawer Bases down the grooves in the Drawer Sides and down into the groove in the Left and Right Drawer Fronts. Step 5 Fit the Drawer Backs Fit the Drawer Backs between the Drawer Sides.
Page 7
Step 8 10mm Prepare the Left Side Tap 6 Dowels into the Left Side. Note: Wooden Dowels must not stick out from the edge by more than 10mm or they may damage other panels. Insert 8 Large Locking Cam Nuts into the Left Side.
Page 8
Step 11 Fit the Legs to the Left Side Push the 2 Legs onto the Left Side. Use a screwdriver to tighten the 6 Large Locking Cam Nuts fitted to the Left Side. Note: Turn the Locking Cam Nuts as far as they will go - more than 1/2 a turn.
Page 9
Step 13 10mm Prepare the Right Side Tap 6 Dowels into the Right Side. Note: Wooden Dowels must not stick out from the edge by more than 10mm or they may damage other panels. Insert 8 Large Locking Cam Nuts into the Right Side.
Page 10
Step 16 Fit the Legs to the Right Side Push the 2 Legs onto the Right Side. Use a screwdriver to tighten the 6 Large Locking Cam Nuts fitted to the Right Side. Note: Turn the Locking Cam Nuts as far as they will go - more than 1/2 a turn.
Page 11
Step 18 Finished Front Edge Prepare the Rail Fit the Bracket to the mark-hole in the Rail using a 13mm Screw. Rail Insert 2 Locking Cam Nuts into the Rail. Step 8 Step 19 Fit the Rail to the Right Side Push the Rail onto the Right Side.
Page 12
Step 21 Fit the Base to the Right Side Push the Base onto the Right Side. Use a screwdriver to tighten the 2 Large Locking Cam Nuts fitted to the Base. Secure the Bracket on the Rail to the mark-hole Finished in the Base using a Front Edge...
Page 13
Step 24 Fit the Left Side Push the Left Side onto the assembly. Use a screwdriver to tighten the 4 Large Locking Cam Nuts fitted to the Base, Rail and Support Rail. Step 8 Step 25 Prepare the Divider Place a Runner on the Divider, as shown.
Page 14
Step 26 Prepare the other surface of the Divider Place a Runner on the Divider, as shown. Slide back the top of Runner and use the 2nd hole from the front to fit the 1st 9mm Screw. Slide the Runner Finished back the other way and Front Edge...
Page 15
Step 28 Prepare the Top Fit the 2 Brackets from the Overbalance Protector Kits to the shallow mark-holes drilled into the Top using 1 of their Screws. Finished Note: Only fit 1 of the Front Edge Screws, the other 1 will be fitted later.
Page 16
Step 30 Prepare the Back Insert 2 Large Locking Cam Nuts into the Back. Step 31 Fit the Back Push the Back up onto the Top. Use a screwdriver to tighten the 2 Large Locking Cam Nuts fitted to the Back. Fix the Back to the back edge of the Base with two 45mm Screws.
Page 17
This unit must be fixed to a wall using the Step 32 2 Overbalance Protector Kits provided Secure the unit to a wall Before fitting the unit to a wall, use a Spirit Level to check the Top of the unit is level, front-to-back and side-to-side in the 3 positions shown.
Page 18
Step 33 The Runners could have sharp edges and Fit the Right Drawer we recommend that you position them using a Screwdriver. Slide both the Runners forward and locate the Drawer Sides between them, lining up their holes with the 2nd 'threaded' holes in the Runners.
Page 19
Step 35 Fit the 2 Doors Line up the 2 screws in the top Hinge with the 2 holes at the top of the Sides and push them in. When the Hinges have been pushed in, Press the Screws into Now push in the other tighten up their Screws the holes in the panels...
Page 20
Step 37 Adjust the Doors if needed Before adjusting the Doors, use a spirit level to check the Base (or Top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
