- Page 1 PPC-5020 12.1” TFT Panel PC (Ver 2.0)
- Page 2 Trademarks PPC-5020 is a registered trademark of ICP Electronics Inc. IBM PC is a registered trademark of International Business Machines Corporation. Intel is a registered trademark of Intel Corporation. Other product names mentioned herein are used for identification purposes only and may be trademarks and/or registered trademarks of their respective companies.
-
Page 3: Table Of Contents
Table of Contents 1. Introduction................. 3 1.1 Checklist ............... 3 1.2 Features ..............3-4 1.3 Specifications............. 4-5 1.4 Dimensions ..............6 2. System Setup................7 2.1 Assembly Diagram............. 7-9 2.2 POS-566/370 CPU Board Installation ......10 2.3 Power Supply Installation ......... 11 2.4 Drive Disk Installation......... -
Page 4: Introduction
1 Introduction The PPC-5020, 12.1" high brightness LCD TFT Panel PC takes advantage of modern flat-panel display technology, coupled with a POS-566/370 CPU board, one hard drive bay and an integrated power supply to ensure minimum size. It is an IBM PC/AT compatible computer specially designed to meet the applications in an industrial environment. -
Page 5: Specifications
LCD Display The PPC-5020 is equipped with a high brightness 12.1" TFT LCD. Power Supply The PPC-5020 is equipped with a standard ACE-816APS 150W power supply with PFC. Touch Screen (option) Aluminum front panel supports both resistive and capacity touch screens. - Page 6 Support driver: Supports DOS, Windows 3.1, 95, 98, NT/Me/2000, WinCE. NET. Please download the capacitive type driver from IEI web site. Environmental specifications Operating Temperature: 0 ~ 50℃ Relative Humidity: 5~95 %, non-condensing Vibration: 5 to 17 Hz, 0.1"double-amplitude displacement, 17 to 640 Hz, 1.5 G peak to peak.
-
Page 7: Dimensions
1.4 Dimensions Front Panel: 340mm x 260mm x 9mm (WxHxD) Cabinet: 310mm x 230mm x 99mm (WxHxD) -
Page 8: System Setup
The following sections of this chapter will help your installation and maintenance. 2.1 Assembly Diagram The Reverse Side of PPC-5020 The diagram shows below the reverse side of PPC-5020. For maintenance, installation or upgrade, you will need to remove the back cover first by unfastening the 9 screws as shown in the diagram. - Page 9 The Reverse Side of the Rear Cabinet The following figure shows the reverse side of the rear cabinet. One HDD and one power supply are accessible for operation on the driver frame. ?? POS-370 ?? POS-566...
- Page 10 The Side View of PPC-5020 On the side panel, you will find one fan and two speakers. Please bear this in mind when mounting the unit. It is placed in to the cabinet and then fastened by four screws.
-
Page 11: Pos-566/370 Cpu Board Installation
2.2 POS-566/370 CPU Board Installation To install the POS-566/370 CPU Board, you have to place the board into the cabinet and then fasten it by four screws. -
Page 12: Power Supply Installation
2.3 Power Supply Installation The standard Power Supply for PPC-5020 is ACE-816APS, which needs to be fastened to the power bracket by 2 screws, and to be fastened in the cabinet by pushing it as far back as possible, as shown in the diagram below. -
Page 13: Drive Disk Installation
2.4 Drive Disk Installation The following sections will inform you how to install the power supply and HDD. As the power supply and HDD are installed in the cabinet, they are reached by opening the back cover. - Page 14 HDD Installation To install the HDD, first fasten the HDD to the HDD cage. Then, push the HDD cage into the HDD bracket and fix it by key lock.
-
Page 15: Speakers And Fan Installation
2.5 Speakers and Fan Installation... -
Page 16: Panel Mounting
2.6 Panel Mounting PPC-5020 is designed for panel mounting. Before mounting the PPC-5020 into panel, you have to check the cut out dimension first. Then mount it into panel by four supporters. Please refer to diagrams below. 312.0 UNIT:mm... -
Page 17: Wall Mounting
PPC-5020 is suitable for Wall mount. 153.00 90.00 4-D4.5... -
Page 18: Arm Mounting
2.7 Arm Mounting PPC-5020 is not only suitable for panel and wall mounting but also has 75/100mm interface pads, making it ideal for arm mounting; and the specification conform to proposed VESA standards. -
Page 19: Rack Mounting
Rack Mounting DM/SRM/PPC serial product provide option rack mount kit for industrial Rack. The following diagram shows how to mount DM/SRM serial product onto the 19" Rack. STEP 2 STEP 1 Rackmount-Kit... -
Page 20: Appendix A Power Supply
Appendix A Power Supply Industrial Power Supply: ACE-816APS series Power Supply High reliability triple output switching Power Supply (just 40.6mm in height) Standard Power Supply: ACE-816APS Efficiency: 68% min PROTECTION: Over Voltage/Load protection and short circuit protection Operating temperature:0°C to 50°C Vibration: 5~17Hz, 0.1”... -
Page 21: Appendix B Display Interface
Appendix B Display Interface A-1: For POS-566 Power on/off switch LCD on/off switch RESET switch ? ? ? ? ? ? ? ??? ? ? ? ???? ? ? ? ? ? ? ? ? ?? ? ? ? ? ? ?? ? ? ? ? ?? ? ?? ? ? ??? ? ? ? ? ? ? ? ????? ? ? ? ? ? ? ? ?? ? ? ? ? ? ? ? ? ?? ? ? ? ? ?? ? ? ? ? -
Page 22: Appendix C. Control Panel Interface
Appendix C Touch Panel Controller The optional touch screen provides RS232 interface and the wire diagram of the controller is shown in the diagram below. Touch Panel Control Board...
