Models using the Pentium (3.3V-ECC) CPU board have two
additional 72-pin SIMM sockets. With the additional sockets, you can
upgrade the memory to 192 MB using 32-MB SIMMs.
Table 1-3 lists some of the possible memory configurations when a
Pentium (3.3V-ECC) CPU board is installed.
Banks 0 and 1 are on the system board;
bank 2 is on the Pentium (3.3V-ECC) CPU
board.
Table 1-3
Some Possible Memory Configurations when Using
the Pentium (3.3V-ECC) CPU Board
Bank 0
S0
S1
S0
4 MB
4 MB
4 MB
4 MB
8 MB
4 MB
4 MB
8 MB
8 MB
8 MB
16 MB
4 MB
4 MB
4 MB
8 MB
8 MB
8 MB
16 MB
16 MB
16 MB
32 MB
32 MB
32 MB
*
S0 and S1 stand for socket 0 and socket 1 respectively.
The above configurations are only some of
the available memory combinations.
can use other combinations as long as you
follow the rules when upgrading memory.
Refer to section 1.3.1.
System Board
Bank 1
Bank 2
S1
S0
8 MB
8 MB
16 MB
16 MB
16 MB
32 MB
32 MB
4 MB
4 MB
4 MB
8 MB
8 MB
8 MB
16 MB
16 MB
16 MB
32 MB
32 MB
32 MB
Total
S1
Memory
8 MB
24 MB
56 MB
112 MB
24 MB
48 MB
96 MB
192 MB
You
1-7
