Models using the dual-Pentium (3.3V) CPU board, four additional
72-pin SIMM sockets are available. With the additional sockets, you
can upgrade the memory up to 256 MB using 32-MB SIMMs.
Table 1-2 lists some of the possible memory configurations when a
dual-Pentium (3.3V) CPU board is installed.
Banks 0 and 1 are on the system board;
banks 2
Pentium (3.3V) CPU board.
Table 1-2
Some Possible Memory Configurations when Using
the Dual-Pentium (3.3V) CPU Board
Bank 0
Bank 1
S0
S1
S0
S1
4 MB
4 MB
4 MB
4 MB
8 MB
8 MB
4 MB
4 MB
8 MB
8 MB
4 MB
4 MB
8 MB
8 MB
4 MB
4 MB
4 MB
4 MB
8 MB
8 MB
8 MB
8 MB
16 MB 16 MB
16 MB 16 MB
32 MB 32 MB
32 MB 32 MB
*
S0 and S1 stand for socket 0 and socket 1 respectively.
The above configurations are only some of
the available memory combinations.
can use other combinations as long as you
follow the rules when upgrading memory.
Refer to section 1.3.1.
1-6
and
3
are
on
the
Bank 2
Bank 3
S0
S1
S0
S1
16 MB 16 MB
16 MB 16 MB
32 MB 32 MB
8 MB
8 MB
32 MB 32 MB
32 MB 32 MB
32 MB 32 MB
32 MB 32 MB
dual-
Total
Memory
8 MB
24 MB
56 MB
120 MB
16 MB
48 MB
192 MB
256 MB
You
User's Guide
