Ipv4 - L2Tp - D-Link COVR-1900 User Manual

Section 3 - Configuration
Choose L2TP (Layer 2 Tunneling Protocol) if your Internet Service Provider (ISP) uses a L2TP connection. Your ISP will provide
you with a username and password. Click Save at any time to save the changes you have made on this page.
Enter the L2TP server IP address provided by your ISP.
L2TP Server
Enter the username provided by your ISP.
Username
Enter the password provided by your ISP.
Password
Select either Always on, On Demand, or Manual.
Reconnect Mode
Configurable when On Demand is selected. Enter a maximum
Maximum Idle Time
idle time during which the Internet connection is maintained
during inactivity. To disable this feature, select Always on as
the reconnect mode.
Select Static IP if your ISP assigned you the IP address, subnet
Address Mode
mask, gateway, and DNS server addresses. In most cases, select
Dynamic IP.
D-Link COVR-1900 User Manual

IPv4 - L2TP

Advanced Settings...
36
