Loop Leader PD6600 Series Loop-Powered Feet & Inches Meter
Instruction Manual
1/8 DIN Loop-Powered Process Meters with NEMA 4X, IP65 Front
•
4-20 mA Input Displayed with ±0.02% FS Accuracy
•
1.5 Volt Drop (4.5 Volt Drop with Backlight)
•
•
0.7" (17.8 mm) 5 Numeric Characters, FT-IN & Fractions, Top Display
•
0.4" (10.2 mm) 8 Alphanumeric Characters Bottom Display
•
Displays Level in Feet & Inches up to 999 Feet, 11 & 15/16 Inches
•
Display Input in Two Different Scales Simultaneously - Great for Level
•
20-Segment Bargraph with Numeric Percent Indication
•
Shallow Depth Case Extends Only 3.6" (91 mm) Behind Panel
(2) Open Collector Outputs Standard; Assigned to Pulse, Alarm, Timer, or Stopwatch
•
(2) Optional Loop-Powered Solid State Relays; Assigned to Alarm, Control, Timer, or Stopwatch
•
Stopwatch & Timer Functions to Drive Relays & Open Collectors
•
Optional Isolated 4-20 mA Analog Output
•
Relay Pump Alternation Based on Level and Runtime
•
•
Display Relay Runtime & Cycle Count via Relay Info Menu
•
Round Horizontal Tank Function; Just Enter Diameter & Length
•
32-Point Linearization
Free PC-Based MeterView XL USB Programming Software
•
HART
Protocol Transparent
•
®
Loop-Powered Backlight with Red Backlight for Alarm Conditions
•
Safe Area Operating Temperature Range: -40 to 167°F (-40 to 75°C)
•
Conformal Coated PCBs for Dust & Humidity Protection
•
Password Protection
•
•
UL & C-UL 61010 Listed for Electrical Safety
•
UL & C-UL Listed as Intrinsically Safe and Nonincendive
•
ATEX and IECEx Certified as Intrinsically Safe
•
Wide Assortment of NEMA 4X Enclosures for up to Ten Meters
•
Light / Horn & Reset Button Accessory
Control Station Accessory for Remote Operation of Digital Input
•
3-Year Warranty
•
PRECISION DIGITAL CORPORATION
233 South Street • Hopkinton MA 01748 USA
Tel (800) 343-1001 • Fax (508) 655-8990
www.predig.com
IECEx
PD6607 Only
