Summary of Contents for Autonics TF3 Series

  • Page 1 Preface USER MANUAL For COMMUNICATION © Copyright Reserved Autonics Co., Ltd.
  • Page 2 Preface © Copyright Reserved Autonics Co., Ltd.
  • Page 3: Preface

    Preface Preface Thank you for purchasing Autonics product. Please familiarize yourself with the information contained in the Safety Precautions section before using this product. This user manual contains information about the product and its proper use, and should be kept in a place where it will be easy to access.
  • Page 4: User Manual Guide

    The manual's content may vary depending on changes to the product's software and other  unforeseen developments within Autonics, and is subject to change without prior notice. Upgrade notice is provided through out homepage. We contrived to describe this manual more easily and correctly. However, if there are any ...
  • Page 5: Communication Protocol

    Communication Protocol Communication Protocol TF3 Series is accepted to Modbus RTU Protocol. Broadcase command is not supportted. © Copyright Reserved Autonics Co., Ltd.
  • Page 6: User Manual For Communication Symbols

    Failure to follow instructions can result in serious injury or death. Failure to follow instructions can lead to a minor injury or product damage. An example of the concerned feature's use. Annotation mark. ※1 © Copyright Reserved Autonics Co., Ltd.
  • Page 7: Safety Precuations

    Do not use water or oil-based detergent when cleaning the unit. Use dry cloth to clean the  unit. Failure to follow this instruction may result in electric shock or fire. © Copyright Reserved Autonics Co., Ltd.
  • Page 8 Keep dust and wire residue from flowing into the unit.  Failure to follow this instruction may result in fire or product damage. The specifications and dimensions of this manual are subject to change and some models may be discontinued without notice. © Copyright Reserved Autonics Co., Ltd.
  • Page 9: Table Of Contents

    Parameter 1 Setting Group ................ 22 2.4.4 Parameter 2 Setting Group ................ 23 2.4.5 Parameter 3 Setting Group ................ 24 2.4.6 Parameter 4 Setting Group ................ 26 2.4.7 Parameter 5 Setting Group ................ 27 © Copyright Reserved Autonics Co., Ltd.
  • Page 10: Modbus Rtu Protocol

    ON-OFF-ON”, 000010(0009 H) to 000009(0008 H) values are “OFF-ON” on Slave. Response(Slave)  Error Check(CRC16) Data Data Slave Address Function Byte Count (000008 to 000001) (000010 to 000009) High CD H 11 H 01 H 02 H 01 H ## H ## H © Copyright Reserved Autonics Co., Ltd.
  • Page 11: Read Input Status(Func02-02H)

    OFF-ON”, 100010(0009 H) to 100009(0008 H) values are “OFF-ON” on Slave. Response(Slave)  Error Check(CRC16) Data Data Slave Address Function Byte Count High (100008 to 100001) (100010 to 100009) CD H 11 H 02 H 02 H 01 H ## H ## H © Copyright Reserved Autonics Co., Ltd.
  • Page 12: Read Holding Registers(Func03-03H)

    Slave. Response(Slave)  Data Data Error Check(CRC16) Slave Address Function Byte Count High High High 11 H 03 H 04 H 02 H 2B H 00 H 64 H ## H ## H © Copyright Reserved Autonics Co., Ltd.
  • Page 13: Read Input Registers(Func04-04H)

    The example when 300001(0000 H) value is “10(A H)”, 300002(0001 H) value is “20(14 H)” on Slave. Response(Slave)  Data Data Error Check(CRC16) Slave Address Function Byte Count High High High 11 H 04 H 04 H 00 H 0A H 00 H 14 H ## H ## H © Copyright Reserved Autonics Co., Ltd.
  • Page 14: Force Single Coil (Func 05-05H)

    ## H Response (Slave)  Starting Address Preset Data Error Check (CRC16) Slave Address Function High High High 11 H 05 H 00 H 00 H FF H 00 H ## H ## H © Copyright Reserved Autonics Co., Ltd.
  • Page 15: Preset Single Registers(Func06-06H)

    ## H 00 H Response(Slave)  Starting Address Preset Data Error Check(CRC16) Slave Address Function High High High 11 H 06 H 00 H 00 H 00 H 0A H ## H ## H © Copyright Reserved Autonics Co., Ltd.
  • Page 16: Preset Multiple Registers(Func16-10H)

    ## H ## H When connecting external devices such as PLC, graphic panel, etc. except when downloading the preset parameters by input type at PC loader program, use Single Register Write, not Multi Register Write. © Copyright Reserved Autonics Co., Ltd.
  • Page 17: Exception Response-Error Code

    03 H E8 H 00 H 01 H ## H ## H Response (Slave)  Function Error Check(CRC16) Slave Address Exception Code (Command)+80 H High 11 H 81 H 02 H ## H ## H © Copyright Reserved Autonics Co., Ltd.
  • Page 18: Modbus Mapping Table

    0: OFF, 1: ON ▲ indicator 100008(0007) Deviation indicator 0: OFF, 1: ON ■ indicator 100009(0008) Deviation indicator 0: OFF, 1: ON ▼ indicator 100010(0009) DI input Digital input 0: OFF, 1: ON 100011 to Reserved 100050 © Copyright Reserved Autonics Co., Ltd.
  • Page 19: Read Input Register.(Func 04) [Func: 04, R/W: R]

    Input status Start Address 0000 300121(0078) Input status Quantity 300122(0079) Holding Register Start Address - 0000 300123(007A) Holding Register Quantity 300124(007B) Input Register Start Address 0000 300125(007C) Input Register Quantity 300126(007D) Channel Quantity 300127(007E) Reserved to 300200(00C7) © Copyright Reserved Autonics Co., Ltd.
  • Page 20 302001 TFD_1st digit data Data value of TFD_10 302002 TFD_2nd digit data Data value of TFD_ 10 302003 TFD_3rd digit data Data value of TFD_ 10 TFD output indicator data 302004 TFD_output data value © Copyright Reserved Autonics Co., Ltd.
  • Page 21: Read Holding Register(Func 03) / Preset Single Register(Func 06) / Preset Multiple Registers(Func 16) [Func: 03/06/16, R/W: R/W]

    0 to 100 Hour SV low limit value to 400052(0033) Max. value ℃/℉ SV high limit value SV low limit value to 400053(0034) Min. value ℃/℉ SV high limit value 400054 to Reserved 400100 © Copyright Reserved Autonics Co., Ltd.
  • Page 22: Parameter 1 Setting Group

    Input correction 3 400109(006C) Delay display period )5 to 1)0 400110(006D) Defrost/Auxiliary output 0: DEF, 1: AUX 400111(006E) Auxiliary output 0: OFF, 1: FAN, 2: ALM 400112(006F) Buzzer 0: OFF, 1: ON 400112 to Reserved 400150 © Copyright Reserved Autonics Co., Ltd.
  • Page 23: Parameter 2 Setting Group

    Alarm delay time after continuous 400170(00A9) 0 to 24 Hour operation Compressor operation cylce when 400171(00AA) 0 to 100 sensor break Compressor duty rate when sensor 400172(00AB) 0 to 100 break 400173 to Reserved 400250 © Copyright Reserved Autonics Co., Ltd.
  • Page 24: Parameter 3 Setting Group

    Prior defrost selection 0: OFF, 1: ON 400230(00E5) Defrost time unit 0: HGH, 1: LOW Alarm delay after defrost/door 400231(00E6) 0 to 24 Hour open Temperature display during 400232(00E7) 0: OFF, 1: ON defrosting © Copyright Reserved Autonics Co., Ltd.
  • Page 25 2 Modbus Mapping Table Factory No(Address) Parameter Description Setting range Unit Note default 400233(00E8) 400234 to Reserved 400250 © Copyright Reserved Autonics Co., Ltd.
  • Page 26: Parameter 4 Setting Group

    2 to 10 (@0 to 1)0) ℉ 0: EF1, 1: EF2, 2: EF3, 400263(0106) Evaporation-fan mode 3: EF4, 4: EF5 Evaporation-fan start-up 400264(0107) )00 to (59 0.00 Min.Sec delay time 400265 to Reserved 400300 © Copyright Reserved Autonics Co., Ltd.
  • Page 27: Parameter 5 Setting Group

    0: OFF, 1: ON 400319(013E) Parameter 4 group lock 0: OFF, 1: ON 400320(013F) Parameter 5 group lock 0: OFF, 1: ON 000: Password OFF 400321(0140) Password 002 to 999: Password ON 400322 to Reserved 400350 © Copyright Reserved Autonics Co., Ltd.
  • Page 28 2 Modbus Mapping Table © Copyright Reserved Autonics Co., Ltd.
  • Page 29 2 Modbus Mapping Table © Copyright Reserved Autonics Co., Ltd. MCT-TF3C1-V1.1-1701US...
