Middle Atlantic Products UD1 Instruction Sheet

One rackspace drawer

Instruction Sheet

UD1

ONE RACKSPACE DRAWER

THANK YOU

Thank you for purchasing the UD1 one rackspace drawer. Please read these instructions

thoroughly before installing/assembling this product.

PRODUCT FEATURES

- Reversible design allows the drawer to be flipped over for use as a slide-out shelf for the

the following applications: writing surface, laptop and keyboard holder.

- Cable knockout at rear of drawer allows for efficient routing of cabling.

I-00333

Page 1

Rev -

Table of Contents

Do you have a question about the UD1 and is the answer not in the manual?

Page 1 Instruction Sheet ONE RACKSPACE DRAWER THANK YOU Thank you for purchasing the UD1 one rackspace drawer. Please read these instructions thoroughly before installing/assembling this product. PRODUCT FEATURES - Reversible design allows the drawer to be flipped over for use as a slide-out shelf for the the following applications: writing surface, laptop and keyboard holder.
Page 2 SUPPLIED HARDWARE (2) Side mounting brackets (For wood installation) (2) 10-32 Wing nuts (4) 6-32 X .25 Self threading screws (2) Rear mount brackets (For use with Rackrail) (4) #10 X .625 Pan head wood screws (2) 10-32 X .5 Pan head machine screws NOTE: Drawer weight capacity is 50 pounds.
Page 3 INSTALLATION WITH SIDE MOUNTING BRACKETS (USE WITH WOOD RACKS/CASES) 1) Attach the drawer to the front rackrail before attaching the side mounting brackets 2) Attach the side mounting brackets to the drawer and then attach to the sides of the rack as shown using the supplied hardware.
Page 4 WARRANTY Middle Atlantic Products, Inc. (the "Company") warrants the UD1 One Rackspace Drawer to be free from defects in material or workmanship under normal use and conditions for a period of (3) three years from date of shipment by the Company.
