Specifications
General Specifications
Range Specifications
Find Quality Products Online at:
Display 3-2/3 (2400 count) Digit LCD with white LED backlight
Polarity Minus sign ( - ) indicates negative polarity
Current sensor Hall effect sensor type
Overload indication "OL" displayed on the LCD
DCA zero adjust One touch zero key
Display rate 2 readings/second, nominal
Battery Two 1.5V AAA batteries
Low Battery indication "BATT" displayed on the LCD
º
Operating conditions 32 F to 86
º
104 F to 122
º
Storage conditions - 14 F to 140
Altitude Operate at less than 3000 meters
Weight 6.2 oz. (176g) including battery
Dimensions 6.5 x 2.6 x 1.3" (164 x 65 x 32mm) (HWD)
Jaw opening 0.7" (18mm)
Standards IEC 1010 Category III 300V, Category II 600V,
Function
DC Current 200A
AC Current 200A
Frequency 40-51Hz
(Auto-Ranging)
51-510Hz
0.51-1kHz
Non-Contact AC Voltage 100VAC to 600VAC 50/60Hz
GlobalTestSupply
www.
º º º º
F (0 C to 30 C) 90%RH; 86
º º º
F (40 C to 50 C) 45%RH
º º º
F (-30 C to 60 C); < 90% Relative Humidity
Range Resolution
0.1A
0.1A
0.01Hz
Input Sensitivity: 2.5A AC RMS min.
0.1Hz
0.001kHz
4
º º º
F to 104 F (30 C to 40 C) 75%RH;
CC
Accuracy (of reading)
± (2.8% + 8 digits)
±(3.0% + 8 digits)
±(1.2% + 5 digits)
MA120-V1.3-EN-3/12
