15.0 - Reader Pinouts

The connector on the CR1100 is an RJ-50
(10P-10C). The pinouts are as follows:

16.0 - CR1100 Maintenance

The CR1100 device needs only a minimum of maintenance to operate. A few tips are given below for maintenance suggestions.
Cleaning the CR1100 Window
CR1100 window should be clean to allow the best performance of the device. The window is the clear plastic piece inside the head of
the reader. Do not touch the window. Your CR1100 uses CMOS technology that is much like a digital camera. A dirty window may
stop the CR1100 from reading barcodes.
If the window becomes dirty, clean it with a soft, non-abrasive cloth or a facial tissue (no lotions or additives) that has been moistened
with water. A mild detergent may be used to clean the window, but the window should be wiped with a water moistened cloth or
tissue after using the detergent.
Technical Support and Returns
For returns or technical support call Code Technical Support at (801) 495-2200. For all returns Code will issue an RMA number
which must be placed on the packing slip when the reader is returned. Visit codecorp.com/support/rma-request for more information.
D032078 _02 CR1100 User Manual
Pin 1 +VIN (5v)
Pin 2 USB_D-
Pin 3 USB_D+
Pin 4 RS232 TX (output from reader)
Pin 5 RS232 RTS (output from reader)
Pin 6 RS232 RX (input to reader)
Pin 7 RS232 CTS (input to reader)
Pin 8 External Trigger (active low input to reader)
Pin 9 N/C
Pin 10 Ground
