13.0 - USB Cable Example with Pinouts

NOTES:
1. Part to be ROHS and Reach compliant.
2. Maximum Voltage Tolerance = 5V +/- 10%.
3. Caution: Exceeding the maximum voltage will void
manufacturer warranty.
CONNECTOR A

14.0 - RS232 Cable Example with Pinouts

NOTES:
1. Part to be ROHS and Reach compliant.
2. Maximum Voltage Tolerance = 5V +/- 10%.
3. Caution: Exceeding the maximum voltage will void
manufacturer warranty.

15.0 - Reader Pinouts

The connector on the CR950 is an RJ-50
(10P-10C). The pinouts are as follows:
D027166_02 User Manual
6 IN 0.5 IN
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
Pin 9
Pin 10
CONNECTOR A NAME
1 VIN
2 DM
3 DP
4 GND
SHELL -
CONNECTOR B
CONN A NAME WIRE CONN B
1 VIN 24 AWG
4 TX 26 AWG
5 RTS 26 AWG
6 RX 26 AWG
7 CTS 26 AWG
10 GND 24 AWG
NC - SHIELD
+VIN (5v)
USB_DM
USB_DP
RS232 TX (output from reader)
RS232 RTS (output from reader)
RS232 RX (input to reader)
RS232 CTS (input to reader)
External Trigger (active low input to reader)
N/C
Ground
WIRE CONNECTOR B
26 AWG 1
24 AWG 2
24 AWG 3
26 AWG 10
SHIELD NC
WIRE CONN C
9 24 AWG TIP
2
8
3
7
5 24 AWG RING
SHELL
9
