10.0 - Reader ID and Firmware Version
To find out the Reader ID and Firmware version, open a text editor program
(i.e., Notepad, Microsoft Word, etc.) and read the Reader ID and Firmware
configuration barcode.
You will see a text string indicating your firmware version and CR1100 ID number.
example: <RD><RR MD="CR1100" /></RD><RD><RR SN="1060000003" /></RD><RD><FW VS="1.1.4 " /></RD><RD><LC GL="" /></RD>
Model Number
<RD><RR MD="CR1100" /></RD><RD><RR SN="1060000003" /></RD><RD><FW VS="1.1.4" /></RD><RD><LC GL="" /></RD>
Note: Code will periodically release new firmware for CR1100, which requires CortexTools2 to update. There are also a number of
drivers (VCOM, OPOS, JPOS) available on the website. For access to the latest drivers, firmware, and support software, please visit our
the product page on our website at codecorp.com/products/code-reader-1100.

11.0 - CR1100 Hole Mounting Pattern

10.4 mm (0.41")
30.2 mm (1.19")
27.0 mm (1.06")
D032078 _02 CR1100 User Manual
Serial Number
34.1 mm (1.34")
15.5 mm (0.6")
31.1 mm (1.23")
Reader ID and Firmware
Firmware
Version
Number
NOTE 1:
Locating holes are 2 mm (0.08")
diameter, hole depth is 1.5 mm
(0.06")
NOTE 2:
Mounting inserts are M3 x 0.5
internal thread, 3.8 mm (0.15")
length.
License Part
Number (if there
is any)
