16.0 - Reader Pinouts

The connector on the CR6000 is an RJ-50
(10P-10C). The pinouts are as follows:

17.0 - CR6000 Maintenance

The CR6000 needs only a minimum of maintenance to operate. A few tips are given below for maintenance suggestions.
Cleaning the CR6000
The CR6000 window should be clean to allow the best performance of the device. The window is the clear plastic piece inside the
head of the reader. Do not touch the window. Your CR6000 uses CMOS technology that is much like a digital camera. A dirty window
may stop the CR6000 from reading barcodes. If the window becomes dirty, clean it with a soft, non-abrasive cloth or a facial tissue (no
lotions or additives) that has been moistened with water. A mild detergent may be used to clean the window, but the window should be
wiped with a water moistened cloth or tissue after using the detergent.
Technical Support and Returns
For returns or technical support visit http://www.codecorp.com/codesupport.php.
D019548_02_CR6000_User_Manual
Pin 1 +VIN (5v)
Pin 2 USB_DM
Pin 3 USB_DP
Pin 4 RS232 TX (output from reader)
Pin 5 RS232 RTS (output from reader)
Pin 6 RS232 RX (input to reader)
Pin 7 RS232 CTS (input to reader)
Pin 8 External Trigger (active low input to reader)
Pin 9 N/C
Pin 10 Ground
