- Page 1 USER MANUAL CR1100 MANUAL VERSION 03 UPDATED: OCTOBER 2022 D032078_03_CR1100_User_Manual...
- Page 2 The software described in this manual may only be used in accordance with the terms of its license agreement. No part of this publication may be reproduced in any form or by any means without written permission from Code Corporation. This includes electronic or mechanical means such as photocopying or recording in information storage and retrieval systems.
-
Page 3: Table Of Contents
14. USB Cable Example with Pinouts ................. 10 15. RS232 Cable Examples with Pinouts ..............10 16. Reader Pinouts ....................11 17. CR1100 Maintenance ..................11 18. Online Resources for the CR1100 ................ 12 19. Contact Code for Support ..................12 20. Warranty ......................12 D032078_03_CR1100_User_Manual... -
Page 4: Cr1100 Readers & Accessories
1. CR1100 Readers & Accessories 1.1 Readers Part Number Description CR1100-K10x Cabled, Light Gray CR1100-K20x Cabled, Dark Gray 1.2 Accessories Part Number Description CRA-US2 CR1xxx - Stand, Light Gray CRA-US3 CR1xxx - Stand, Dark Gray CRA-MB9 CR1xxx - Vice Clamp Mount CRA-WMB3 CR1xxx - Wall Mount Bracket (Light Gray) 1.3 Power Supplies... -
Page 5: Unpacking & Installation
2. Unpacking & Installation 2.1 CR1100 & Cables CR1100 USB Cable RS232 Cable 5VDC Power Supply 2.2 Universal Stand D032078_03_CR1100_User_Manual... -
Page 6: Attaching & Detaching A Cable
3. Attaching & Detaching a Cable 4. Setup Plug In RS232 Wait 2 seconds 2 Sec. LED will Flash Reader will beep D032078_03_CR1100_User_Manual... -
Page 7: Using A Cr1100 Outside Of A Universal Stand
10 cm 10 cm 7. Typical Reading Ranges Test Barcode Min Inches (mm) Max Inches (mm) 3 mil Code 39 3.3” (84 mm) 4.3” (109 mm) 7.5 mil Code 39 1.9” (47 mm) 7.0” (177 mm) 10.5 mil GS1 DataBar 0.6”... -
Page 8: Reader Feedback
Successful decode and data transfer Green LED flashes 1 beep Configuration code successfully decoded and processed Green LED flashes 2 beeps Configuration code successfully decoded but wasn’t successfully processed Green LED flashes 4 beeps Downloading file/firmware Amber LED flashes None... -
Page 9: Reader Id, Firmware Version & License
Number (if there is any) <RD><RR MD=”CR1100” /></RD><RD><RR SN=”1060000003” /></RD><RD><FW VS=”1.1.4” /></RD><RD><LC GL=”” /></RD> Note: Code will periodically release new firmware for CR1100 readers. For information on the latest firmware, please see codecorp.com/products/code-reader-1100. 12. CR1100 Hole Mounting Pattern 34.1 mm (1.34”) NOTE 1: 15.5 mm (0.6”) -
Page 10: Cr1100 Overall Dimensions
13. CR1100 Overall Dimensions 67.5 mm (2.7”) 29.7 mm (1.2”) 52.5 mm (2.1”) 14. USB Cable Example with Pinouts Notes: CONNECTOR A NAME CONNECTOR B 1. Part to be RoHS and Reach compliant. 2. Maximum voltage tolerance = 5V +/- 10% 3. -
Page 11: Reader Pinouts
16. Reader Pinouts The connector on the CR1100 is Pin 1 +VIN (5v) an RJ-50 (10P-10C). Pinouts: Pin 2 USB_D- Pin 3 USB_D+ Pin 4 RS232 TX (output from reader) Pin 5 RS232 RTS (output from reader) Pin 6 RS232 RX (input to reader) Pin 7 RS232 CTS (input to reader) Pin 8... -
Page 12: Online Resources For The Cr1100
• Firmware version Code Support will respond by telephone or email. If it is deemed necessary to return the device to Code for repair, Code Support will provide a Return Authorization (RMA) Number and shipping instructions. Packaging or shipping improperly may result in damage to the device and void the warranty.
