- Page 1 2 TONNE SERVICE JACK MODEL NO: CTJ2GLS PART NO: 7621026 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC1216...
-
Page 2: Specifications
INTRODUCTION Thank you for purchasing this CLARKE Long Chassis Service Jack. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: Safety Precautions
9. Do not try to lift more then the rated load for the jack, (See “Specifications” on page 2.) 10. Do not use the jack if an oil leak is apparent. Consult your Clarke dealer. 11. Consult the vehicle handbook to determine the correct lifting points. -
Page 4: Before Use
BEFORE USE 1. Press down hard enough on the yoke to overcome the resistance of the return spring and remove the packing clip shown. 2. Attach the foot pedal using the socket-headed bolt as shown. 3. Loosen the nut and pinch bolt just beside the hole for the handle, to make it easier to insert the handle into the socket. -
Page 5: Operation
PURGING AIR FROM THE SYSTEM If air bubbles become trapped inside the hydraulic system during shipping or transport, the efficiency of the jack will be reduced and the jack will feel spongy. 1. Turn the control valve knob counter-clockwise, relieving the pressure inside the jack. -
Page 6: Maintenance
Clean exposed areas with a clean oiled cloth. In the event of damage or broken components, replacements are available from Clarke Parts & Service. CHECKING/TOPPING UP THE OIL LEVEL If the jack has been stored for long periods, check for oil leaks before use. If... -
Page 7: Environmental Protection
• Oil must be level with the bottom of the filler hole. 4. Top up if necessary with Clarke hydraulic oil available from your Clarke dealer (part number 3050830). 5. Dispose of old/spilled oil appropriately and wipe up any spillage. -
Page 8: Troubleshooting
Purge the system as on page 5 system Jack will not Return spring may Return to your Clarke dealer for lower completely be faulty or parts repair corroded. If any of these remedies fail to restore your jack, consult your Clarke dealer. -
Page 9: Declaration Of Conformity
DECLARATION OF CONFORMITY... -
Page 10: Component Parts
COMPONENT PARTS... -
Page 11: Component Parts List
COMPONENT PARTS LIST No Description No Description No Description Nut M6 Seal Pedal Link Washer Steel Ball 5 dia Nut M10 Front Wheel Oil Filler Plug Foot Pedal Bush Hydraulic Ram Bolt Left Frame Circlip Torsion Shaft A Front Wheel Axle O-Ring Retainer Bolt M10x60 Right Frame...
