3. Installation

Ceiling Mounting
■
1. Remove the ceiling tile.
2. Place the mounting bracket in the center of the ceiling tile. Mark the positions
of the three mounting slots and a hole for the Ethernet cable to feed through.
Mark of the hole for Ethernet
cable to feed through
Note:
Make sure the thickness of the ceiling is less than 18mm and
■
the ceiling can bear at least five kilograms.
It is NOT recommended to mount the EAP on a low-strength
■
material, such as gypsum ceiling panel. If no other choice is
available, make sure you add a piece of strong material under
the wing nuts to ensure the EAP is mounted solidly.
L
L≈40mm
06
