- Page 1 Quick Setup Guide for Standalone Omada Access Points EAP110 / EAP115 / EAP225 / EAP245 / EAP320 / EAP330 / EAP115-Wall EAP110-Outdoor / EAP225-Outdoor / EAP225-Wall 1910012420 REV1.0.1 May 2018...
- Page 2 To configure and manage mass EAPs (usually more than three), you can use EAP controller. For detailed instructions about how to use EAP Controller, visit http://www. tp-link.com/en/download/EAP-Controller.html to download EAP Controller and its User Guide. To configure a few EAPs (usually less than three), you can directly use the management interface of each EAP via a web browser.
- Page 3 Step2: Logging In to the EAP Device There are two methods to log in to the EAP. You can choose one as you like: Method 1: Log In via the Domain Name Method 2: Log in via the IP Address of the EAP Note: EAP320 and EAP330 are not currently available for login via domain name.
- Page 4 4. Launch a web browser on the client device and enter http://tplinkeap.net in the address bar to load the login page of the EAP. Use admin for both of the username and password to log in. Tips If you cannot log in to the EAP via the domain name, try the operations below for troubleshooting: •...
- Page 5 IP address of your EAP according to its MAC address. The MAC address can be found at the bottom of the EAP. • Go to http://www.tp-link.com/en/download/EAP-Controller.html#EAP_Discovery_ Tool to download EAP Discovery Utility. EAP Discovery Utility is a software that can...
- Page 6 on the PC, and find the IP address of the EAP. In the following figure, the IP address of the EAP is 192.168.0.5. 2. Launch a web browser and enter 192.168.0.5 in the address bar to load the login page of the EAP. Use admin for both of the username and password to log in. 3. In the pop-up window, configure a new username and a new password for your user account.
- Page 7 4. Use the new username and password to log in. Tips The EAP is preset with a default IP 192.168.0.254, which you can use to log in to its web management page. Follow the steps below: 1. Connect the EAP to your computer with an Ethernet Cable. 2. Assign a static IP address 192.168.0.X (X ranges between 2 and 253) together with the subnet mask 255.255.255.0 to your computer.
- Page 8 Follow the steps below to add a new SSID: 1. Go to the Wireless > Wireless Settings page. If your EAP is a dual-band device, click to choose a frequency band on which the new SSID will be created. In the SSIDs section, click to create a new SSID on the chosen band.
- Page 9 The configurations for editing the SSID will take effect immediately. So you should • reconnect to the wireless network of the EAP. https://www.tp-link.com/us/support/ For more detailed configurations, visit • download the User Guide of EAP in the download center.
- Page 10 Specifications are subject to change without notice. is a registered trademark of TP-Link Technologies Co., Ltd. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-Link Technologies Co., Ltd.
