7. Feed the Ethernet cable through the hole and set the ceiling tile back into
place.
8. Connect the Ethernet cable to the ETHERNET port.
Wall Mounting
■
There are two wall-mounting slots on the back of the mounting bracket. To mount
the EAP on a wall, please follow the steps below.
1. Make two small pencil marks on the wall. Make sure the two marks are level
and should be 98.6mm apart.
2. Use a drill with the appropriate size drill bit to drill two 4mm holes through the
center of your marks.
3. Insert the plastic wall anchors into the 4mm holes and drive the self-tapping
screws into the anchors.
09
Wall
4mm hole
