1 Getting Started

1.1 Introduction

xWR6843ISK/IWR6843ISK-ODS/ IWR6843AOPEVM and MMWAVEICBOOST are part of mmWave EVMs
hardware. The xWR6843 antenna board from Texas Instruments is an easy-to-use evaluation module for the
xWR6843 mmWave sensing device. This board contains 60-GHz mmWave Radar transceiver in which antennas
are etched on PCB or on packager and act as the Radar front-end board. The MMWAVEICBOOST is an add-on
board used with TI's mmWave sensor used in all starter kits to provide more interfaces and PC connectivity to
the mmWave sensors. The MMWAVEICBOOST board provides an interface for the mmWave Studio tool to
configure the Radar device and capture the raw analog-to-digital converter (ADC) data, using a capture board
such as DCA1000 evaluation module (EVM). xWR6843 antenna EVMs and MMWAVEICBOOST contains
everything required to start developing software for on-chip C67x DSP core and low-power ARM R4F controllers.
It provides an interface to the MSP43xx boards through 40-pin LaunchPad
Revision currently available on product page
MMWAVEICBOOST Rev. B
AWR6843ISK Rev. C
IWR6843ISK Rev. B
IWR6843ISK-ODS Rev. B
IWR6843AOPEVM Rev. F
All older revisions not listed are deprecated and may contain deprecated silicon version

1.2 Key Features

Tuning Frequency
Number of Receivers
Number of Transmitter
Processing
Memory
Antenna
Azimuth FOV
(deg)#GUID-868BBA8D-49E8-4A
86-B97C-66CF39ECC363/
ID-5360B3FE-311B-48B4-
FC43-23661A94EA2C
Azimuth Angular Resolution
(deg)#GUID-868BBA8D-49E8-4A
86-B97C-66CF39ECC363/
ID-48D14D26-
EDC8-42F7-8864-7CD5A4FDFA
A9
Elevation FOV
(deg)#GUID-868BBA8D-49E8-4A
86-B97C-66CF39ECC363/
ID-5360B3FE-311B-48B4-
FC43-23661A94EA2C
SWRU546D – OCTOBER 2018 – REVISED NOVEMBER 2020
Submit Document Feedback
Note
Integrated Antenna 60-GHz
Intelligent Edge Sensor
IWR6843AoPEVM
60-64 GHz
4
3
• MCU
• FFT accelerator
• DSP
1.75 MB
Antenna on Package
+/- 60
29
+/- 60
Copyright © 2020 Texas Instruments Incorporated
™ / BoosterPack
Silicon Version
-
ES2
ES2
ES2
ES2
High Performance 60-GHz
Intelligent Edge Sensor
xWR6843ISK
60-64 GHz
4
3
• MCU
• FFT accelerator
• DSP
1.75 MB
Antenna on PCB
+/- 60
15
+/- 15
mmWaveICBoost and Antenna Module
Getting Started
™ connectors.
60-GHz Intelligent Edge Sensor
IWR6843ISK-ODS
60-64 GHz
4
3
• MCU
• FFT accelerator
• DSP
1.75 MB
Antenna on PCB
+/- 60
29
+/- 60
