Texas Instruments MSP430G2744DA Manual

1 Device Overview
1.1 Features
1
• Low Supply-Voltage Range: 1.8 V to 3.6 V
• Ultra-Low Power Consumption
– Active Mode: 270 µA at 1 MHz, 2.2 V
– Standby Mode: 1 µA
– Off Mode (RAM Retention): 0.1 µA
• Ultra-Fast Wakeup From Standby Mode in Less
Than 1 µs
• 16-Bit RISC Architecture, 62.5-ns Instruction Cycle
Time
• Basic Clock Module Configurations
– Internal Frequencies up to 16 MHz With Four
Calibrated Frequencies
– Internal Very-Low-Power Low-Frequency (LF)
Oscillator
– 32-kHz Crystal
– High-Frequency (HF) Crystal up to 16 MHz
– Resonator
– External Digital Clock Source
– External Resistor
• 16-Bit Timer_A With Three Capture/Compare
Registers
• 16-Bit Timer_B With Three Capture/Compare
Registers
• Universal Serial Communication Interface (USCI)
– Enhanced UART Supports Automatic Baud-
Rate Detection (LIN)
– IrDA Encoder and Decoder
– Synchronous SPI
2
– I C
1.2 Applications
• Sensor Systems
1.3

Description

The Texas Instruments MSP430™ family of ultra-low-power microcontrollers consists of several devices
featuring different sets of peripherals targeted for various applications. The architecture, combined with
five low-power modes, is optimized to achieve extended battery life in portable measurement applications.
The device features a powerful 16-bit RISC CPU, 16-bit registers, and constant generators that contribute
to maximum code efficiency. The digitally controlled oscillator (DCO) allows the device to wake up from
low-power modes to active mode in less than 1 µs.
The MSP430G2x44 series is an ultra-low-power mixed-signal microcontroller with two built-in 16-bit timers,
a universal serial communication interface (USCI), 10-bit analog-to-digital converter (ADC) with integrated
reference and data transfer controller (DTC), and 32 I/O pins.
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
Sample &
Product
Buy
Folder
MSP430G2x44 Mixed-Signal Microcontrollers
Tools &
Technical
Software
Documents
MSP430G2744, MSP430G2544, MSP430G2444
SLAS892C – MARCH 2013 – REVISED SEPTEMBER 2014
• 10-Bit 200-ksps Analog-to-Digital Converter (ADC)
With Internal Reference, Sample-and-Hold,
Autoscan, and Data Transfer Controller
• Brownout Detector
• Serial Onboard Programming, No External
Programming Voltage Needed, Programmable
Code Protection by Security Fuse
• Bootstrap Loader (BSL)
• On-Chip Emulation Module
• Family Members
– MSP430G2444
• 8KB + 256B Flash Memory
• 512B RAM
– MSP430G2544
• 16KB + 256B Flash Memory
• 512B RAM
– MSP430G2744
• 32KB + 256B Flash Memory
• 1KB RAM
• Section 3 Summarizes the Available Family
Members
• Package Options
– TSSOP: 38 Pin (DA)
– QFN: 40 Pin (RHA)
– DSBGA: 49 Pin (YFF)
– PDIP: 40 Pin (N) Available in Sampling
Quantities as
• For Complete Module Descriptions, See the
MSP430x2xx Family User's Guide (SLAU144)
• Radio-Frequency Sensor Front End
Support &
Community
PMS430G2744IN40
