Control Port Operation
Shelf: 1
Unacknowledged Alarms:
This utility programs the H2TUC.
program used must support Y-Modem file transfers and have access to
the software binary file (*.bin).

Figure 49. Download H2TU-C via Y-Modem Menu

Figure 50 illustrates a Flash upgrade session in progress.
Shelf: 1
Unacknowledged Alarms:
...Requesting SCU maintenance channel for Flash Upgrade process
Setup Instructions:
[Note: Your terminal program may differ slightly]
1. Select "Send File" from Transfer options.
2. Set "Transfer Protocol" to the following:
Xmodem(CRC) or Ymodem
3. Select appropriate binary file (*.BIN) to upload.
4. Upload File.
[Note: The screen will start displaying C's - this is normal.]
=CCCC

Figure 50. Flash Upgrade, Y-Modem in Progress

48
Slot: 14 Total Access System
Circuit ID:HntsvlALMn0103
Download H2TU-C via Y-Modem
1. Start Transfer
2. Abort
Selection:
Slot: 14 Total Access System
MAJOR
Circuit ID:
HDSL2 for General Distribution Installation and Maintenance Practice
INFO
The VT100 terminal emulation
INFO
03/01/05 10:59
03/01/05 10:59
61223HDSL2L2-5B
