Figure 46. Histogram Screen; Reset Splice Detector - ADTRAN HDSL2 Installation And Maintenance Practice

HDSL2 for General Distribution Installation and Maintenance Practice
Circuit ID:
H2TUC Press C to Change
Splice |
(feet) |
------ |
0000 |
0250 |
0530 |
0810 |
1090 |
1370 |
1650 |
1930 |
2210 |
2490 |
2770 |
3050 |
3330 |
3610 |

Reset Splice Detector

Choosing Reset Splice Detector will prompt to make sure a reset is desired. If
the splice detector will re-initialize and start running again.
61223HDSL2L2-5B
Press ESC to return to previous menu
Splice Histogram Screen
H2TUC H2TUR
----- -----
00 00
09 00
00 00
00 00
00 00
00 00
00 00
00 00
00 00
00 00
00 00
00 00
00 00
00 00

Figure 46. Histogram Screen

11/05/04 09:29:45
H2TUC
Splice |
(feet) | H2TUC H2TUR
------ | ----- -----
3890 | 00 00
4170 | 00 00
4455 | 00 00
4740 | 00 00
5025 | 00 00
5310 | 00 00
5595 | 00 00
5880 | 00 00
6165 | 00 00
6450 | 00 00
6735 | 00 00
7020 | 00 00
7305 | 00 00
7590 | 00 00
