Figure 14. Total Access 3000 H2Tu-C Main Menu Screen; Figure 15. Adtran Information Screen; Hdsl2 Unit Information - ADTRAN HDSL2 Installation And Maintenance Practice

HDSL2 for General Distribution Installation and Maintenance Practice
Shelf: 1
Unacknowledged Alarms: None

Figure 14. Total Access 3000 H2TU-C Main Menu Screen

HDSL2 Unit Information

The Unit Information screen
component in the HDSL2 circuit. ADTRAN Technical Support contact numbers are also
available from the Unit Information screen. This screen is shown as an example of an actual
HDSL2 screen.
Circuit ID:HNTSVLALHDSL2
--------------------- For Information or Technical Support --------------------
Support Hours ( Normal 7am - 7pm CST, Emergency 7 days x 24 hours )
Phone: 800.726.8663 / 888.873.HDSL
-------------------------------------------------------------------------------
61223HDSL2L2-5B
Slot: 15 Total Access System
Circuit ID:
HDSL2 Main Menu
1. HDSL2 Unit Information
2. Provisioning
3. Status
4. Loopbacks and Test
5. Performance Monitoring
6. Scratch Pad, Ckt ID
7. Alarm History
8. Event History
9. System Status/PM Report
10. Clear PM and Alarm Histories
11. Troubleshooting
12. Flash Upgrade
Selection:
(Figure 15) provides detailed product information on each
Press ESC to return to previous menu
ADTRAN
901 Explorer Boulevard
Huntsville, Alabama 35806-2807
ADTN H2TU-C
P/N: 1223001L2
S/N: FD14E3648
CLEI: T1L7J2MAAA
Manf: 08/08/2004
Ver: A07

Figure 15. ADTRAN Information Screen

Fax: 256.963.6217 Internet: www.adtran.com
ADTN H2TU-R
P/N: 1223026L2
S/N: 123456789
CLEI: T1L8MOKCAA
Manf: 08/01/2004
Ver: A09
Control Port Operation
03/01/05 09:29
03/01/05 09:29:45
