Control Port Operation

Screens

The screens illustrated in
the ADTRAN HDSL2 technology. The circuit includes an H2TU-C module and an H2TU-R
module.
Logon to Main Menu
A terminal session is initiated by entering multiple spacebar characters, which are used by an
H2TU-C module to determine the speed of the terminal. Once the speed has been determined,
the ADTRAN HDSL2 Main Menu is displayed from which the various Operation, Adminis-
trative, Maintenance, and Provisioning (OAM&P) screens may be accessed
display a particular screen from the menu, press the number key associated with the screen
title, and press the
E
When the ADC HiGain
3192M DB-9 is disabled. Terminal screens must be accessed from
any one of these HMUs:
Circuit ID:HNTSVLALHDSL2
18
Figure 10 through
key.
NTER
Management Unit (HMU) is installed, the
®
HMU-319-L7A
HMU-319-L7AV307
HMU-319-L7A32.
Adtran HDSL2 Main Menu
1. HDSL2 Unit Information
2. Provisioning
3. Span Status
4. Loopbacks and Test
5. Performance History
6. Scratch Pad, Ckt ID, Time/Date
7. Terminal Modes
8. Alarm History
9. Event History
10. System PM/Screen Report
11. Clear PM and Alarm Histories
12. Troubleshooting
13. Virtual Terminal Control
Selection:

Figure 10. ADTRAN HDSL2 Main Menu

HDSL2 for General Distribution Installation and Maintenance Practice
Figure 47 are for an HDSL2 circuit deployed with
NOTE
(Figure 10). To
03/01/05 09:29:45
61223HDSL2L2-5B
