Control Port Operation
Shelf: 1
Unacknowledged Alarms: None
The Access Module Menus screen
Total Access 3000 shelf. Select the corresponding channel slot number for the desired
H2TU-C. To the right of each access module listed, the current alarm state is indicated.
When the module is selected, the ADTRAN HDSL2 Main Menu is displayed, from which the
various Operation, Administrative, Maintenance, and Provisioning (OAM&P) screens are
accessed (Figure 14). To display a particular screen from the menu, press the number key
associated with the screen title, and then press the
Shelf: 1
Unacknowledged Alarms: None
20
HDSL2 for General Distribution Installation and Maintenance Practice
Total Access System
Total Access
1. System Controller
2. Common A - [.....]
3. Common B - [.....]
4. Access Modules
5. System Alarms
6. Network Management
7. Logoff
Selection:
'?' - System Help Screen

Figure 12. Total Access Main Menu

(Figure 13) will display the access modules occupying the
Total Access System
Access Module Menus
1 - H2TU-C L2... [None]
2 - ............ [None]
3 - ............ [None]
4 - ............ [None]
5 - ............ [None]
6 - ............ [None]
7 - ............ [None]
8 - ............ [None]
9 - ............ [None]
10 - ............ [None]
11 - ............ [None]
12 - ............ [None]
13 - ............ [None]
14 - ............ [None]
Enter Channel Slot Number :

Figure 13. Access Module Menus Screen

03/01/05 09:29
key.
E
NTER
03/01/05 09:29
15 - ............ [None]
16 - ............ [None]
17 - ............ [None]
18 - ............ [None]
19 - ............ [None]
20 - ............ [None]
21 - ............ [None]
22 - ............ [None]
23 - ............ [None]
24 - ............ [None]
25 - ............ [None]
26 - ............ [None]
27 - ............ [None]
28 - ............ [None]
