3. Set up the power supply
Selecting the power scheme and installing it:
See Appendix C: Setting up the Power Supply (p 23).
You can verify the NJ95 Network Jack Installation by checking
the LEDs.
LED
Description
(LAN)
(Power)
CAUTION: Make sure the port on the wiring closet
switch to which the NJ95 is connected is configured as a
standard MDI port.
14
On—The NJ95 is connected to the network and a
I
link has been established.
Off—There is no connection to the network.
I
On—The NJ95 is receiving power (local or via the
I
network).
Off—The NJ95 is not receiving power.
