User Guide
1 NJ95 Main Unit
2a Universal Wall
Plate
(Included)
2b Manufacturer-
Specific Wall Plate
(purchased
separately – For
available plates see
www.3Com.com/
products and
Appendix E)
3 LEDs
4 Power Socket
4
Allow up to four devices to be connected to the
network.
Used to mount the main unit – pass through "wall
plate" and non manufacturer-specific.
Used to Mount the Main Unit – Mount the
specific connectors on the Wall Plate. One of the
connectors would serve to connect the switched
ports to the Network.
The second connector referred to as an optional
port bypasses the functionality of the switch.
Allows connection to a separate network segment
or to an analog or digital PBX telephone network
Indicates network connection status.
Indicates NJ95 power status.
NJ95 can be powered from a local power supply
(available for purchase from 3Com); required if
your network does not support Power Over
Ethernet (PoE).
