SYSTEM MONITORING PROCEDURE

12
The following system procedures are intended for system administrators as a guide to monitor the
MIP system health periodically. Network logging issues might be caused by a variety of causes such
as missing media streams, configuration issues, environmental changes or unexpected scenarios
encountered by the system.

Checking Probe Status

12.1
Access Probe and Encoder status by clicking <Tools><Configuration> and select a <Probe Group>
to open the respective Group page. Probes and Encoder status is denoted by a color coded icon to
the left of the name.
necessarily that all encoders are working normally. To check on individual encoders expand the
display to show encoders.

Encoder Status

12.2
Encoder status is a Green, Red or Amber ball to the left of the item name.
Hibernation – Probe is down as scheduled.
Dummy Mode – Source is not available.
If the Probe is accessible the status icon is green.
If not it is red. Green simply indicates the Probe server is accessible, not
Probe or Encoder is operating normally.
Probe or Encoder has stopped and needs to restart.
Probe or Encoder is rebooting.
Figure: Group, Probe and Encoder Status
