Summary of Contents for Caraudio-Systems MD-VW01
- Page 1 MD-VW01...
-
Page 2: Table Of Contents
Contents: Contents ............................2 Safety Instructions ........................3 Service / Support ........................4 Shipment ............................. 4 Product Description ........................5 Installation of the harness with MULTI200 ................5-7 Function and control ........................ 8-9 Button assignment for MFD1 System ..................9 Button assignment for AUDI Navi Plus System .............. -
Page 3: Safety Instructions
Safety Instructions: 1. Read through mounting guidelines: Please read through all safety instructions and handling directions intently before installation and start up of the device. 2. Keep mounting guidelines: Keep the instruction manual and safety instructions for potential further reference. 3. -
Page 4: Service / Support
Date of purchase, your name and address, item number and the type of your vehicle. Shipment: Harness MD-VW01 Manual iPod® ist ein eingetragenes Markenzeichen der Apple Computer, Inc. -
Page 5: Product Description
Product Description: Article: MD-VW01 Harness for Multimedia Interface “MULTI200” Features: For use with the following navigation systems: VW and SKODA with MFD1: Golf4, Bora, Passat, T4, Octavia I, Superb AUDI with Navi Plus: A2, A3, A4, A6, A8... - Page 6 2. Connect the 10pin plug of the harness to the navigation unit. 3. Connect the blue cable from the harness to pin 26 of the 26 pin connector of the navigation unit. Connect the yellow cable to pin 13 of the 26 pin connector. Connect the black cable to ground (power connector pin 8) and the red cable to 12V battery (power connector pin 7).
- Page 7 7. To use the rear view camera function you have to open the interface. As seen on the right side you have to close the connection with the middle jumper. Connect the video signal of the aftermarket rear view camera to the "R-CAM IN" plug. The green cable of the harness can be used to supply power (+12V) to the rear view camera.
-
Page 8: Function And Control
Function and control: Activation: Pressing „Audio“ in a VW or Skoda respectively “Radio/CD/TV“ in an Audi activates the TV/AV input. Device assignment: Due to the lack of a display connection to MDF1 and Navi+, the setup has to be done without optical feedback. -
Page 9: Button Assignment For Mfd1 System
Control: The video sources can be controlled with the buttons at the navigation system. You can switch between AV1 / AV2 by pressing the right turn knob more than 3 seconds. See below for all buttons. Button assignment for MFD I: Button assignment part 1 ●─●... -
Page 10: Button Assignment For Audi Navi Plus System
Button assignment for AUDI Navi Plus: Button assignment part 1 ●─● AUDI Navi Plus ●─● Modell 5 (3Sec) 6 (3Sec) DVD / DVDC TRACK- TRACK+ ← → POWER STOP SETTINGS MENU ENTER DVB-T TUNER CH - CH + ← → POWER EXIT SETTINGS MENU... - Page 11 Caraudio-Systems Vertriebs GmbH manufacturer/distribution In den Fuchslöchern 3 D-67240 Bobenheim-Roxheim email support@caraudio-systems.de Legal disclaimer: Mentioned company and trademarks, as well as product names/codes are registered trademarks ® of their corresponding legal owners. Rev. 1 / 26.05.2009...
