  • Page 1 F-G20 F-G20-BASE OWNER’S MANUAL OWNER’S MANUAL CAUTION! CAUTION! Read all precautions and instructions in this manual before using this equipment. Read all precautions and instructions in this manual before using this equipment.
  • Page 2 Table of Contents spare part list........................3-8 Assembly step 1........................9-12 Assembly step 2........................13-16 Assembly step 3........................17-19 Assembly step 4........................20-22 Assembly step 5........................23-27 Assembly step 6........................28-30 Assembly step 7........................31-33 Assembly step 8........................34-35 Assembly step 9........................36-38 Assembly step 10......................39-42 Assembly step 11......................43-46 Assembly step 12......................47-49 Assembly step 13......................50-56 Extra parts ........................57-60...
  • Page 3 Spare parts list Description Note Qty. ground tube front guide rod φ25*2050 left stand tube connect support tube right stand tube crush pad hexagon bolt M10*95 washer Φ10 lock nut hexagon bolt M10*70 hang shaft hexagon bolt M10*16 3070 ground tube square tube □50*50*t1.5 oval mat...
  • Page 4 Spare parts list Description Note Qty. hexagonal socket head cap screw M6*16 3060 hook-right 3035 barbell inner rod spring gasket Φ6 hook-left safety catch lock nut safety hook 54511 3070 chin bar 50 connect plate-2 hole 120*50*T3 3070 chin tube square tube 50*25 up decorate plate...
  • Page 5 Spare parts list Description Note Qty. Injection molded insert nut high pull handle outer catch collar Φ38.6*Φ32.8*25 hexagon socket set screw M10*25 pulley frame decorate adjust plate Φ14*49*T1.5 powder metallurgy sleeve Φ20*Φ16*Φ10.5*21.5 wire-ball bolt 32 tube plug pulley adjust plate 3070 wire gravity block bolt wire-splice head...
  • Page 6 Spare parts list Description Note Qty. limit ring circle tube plug Φ25*1.5 up connection tube up cross tube hook back stand tube concave plate 120*52*T3 back connection tube hook finger cover Φ8*100 3070 back stand tube barbell bar inner tube 3070 kettle fix frame 3070 small handle fix tube aluminium cap...
  • Page 7 Spare parts list long safety catch-outer rubber 387MM long safety catch-right long safety catch-right welding 3070 footplate lock pin back support tube 3070 waist pad hexagon bolt M8*70 move hook move hook plate hook connect shaft powder metallurgy sleeve Φ26*Φ16*12 move hook-right 3070 short safety catch -left roller shaft...
  • Page 8 Spare parts list Description Note Qty. T shape pin T shape lining sleeve U shape fastener catch hexagon socket button head screws M8*16 washer Φ8 spring gasket move hook plate hexagon socket button head bolt M8*40 traingular handle Bolt length meter...
  • Page 9 Assembly step-1 explosion drawing Description Note Qty. ground tube front guide rod φ25*2050 left stand tube connect support tube right stand tube crush pad hexagon bolt M10*95 washer Φ10 lock nut hexagon bolt M10*70 hang shaft hexagon bolt M10*16...
  • Page 10 Factory Assembly Drawing Description Note Qty. 3070 ground tube square tube □50*50*t1.5 oval mat 131*80*14 plain half hexagon rivet nut fix plate-bend hexagon bolt M10*20 spring gasket Φ10 ground tube washer Φ10 QTY: 2PCS/SET Description Note Qty. left stand tube hang shaft Φ25*M12*98 tube plug...
  • Page 11 Factory Assembly Drawing Description Note Qty. 3070 right stand tube hang shaft Φ25*M12*98 tube plug □50*70*t1.5 square tube □50*50*t1.5 plain half hexagon rivet nut hexagon bolt M12*25 spring gasket Φ12 washer Φ12 3070 right stand tube QTY: 1PCS/SET...
  • Page 12 Assembly step-1 drawing 1250 1250 1250 1250 857.27 857.27 857.27 857.27 1250 1250 1250 1250 ATTENTION: Please attention the size of the back and front. To void the size back high pull don’t suitble. Assembly step-1 installation instruction 1 Assembly guide rod-2 on ground tube-1,then cover crush pad-6 on guide rod-2 using M10*16 hexagon bolt- 12,Φ10 washer-8.
  • Page 13 Assembly step-2 explosion drawing Description Note Qty. sliding sleeve barbell bar safety catch-right rubber crush Φ60*Φ26-25 safety catch-left front guide rod φ25*2050 weight stack-130KG hang shaft magnetic pin hexagon bolt M10*20 washer Φ10 spring gasket Φ10...
  • Page 14 Factory Assembly Drawing Description Note Qty. sliding tube rubber cover sliding tube lining bearing LM25UU bearing 6005 QTY: 2PCS/SET spring catch collar Φ40 Description Note Qty. aluminum rod Φ30*1158*T2.5 hexagonal socket head cap screw M6*16 3060 hook-right barbell bar 3035 barbell inner rod QTY: 1PC/SET spring gasket Φ6...
  • Page 15 Factory Assembly Drawing Description Note Qty. lining bearing LM25UU spring catch collar Φ40 safety catch lock nut washer Φ12 safety catch 54511 safety hook-right QTY: 1PC/SET Description Note Qty. lining bearing LM25UU spring catch collar Φ40 safety catch safety hook 54511 lock nut washer...
  • Page 16 Assembly step-2 drawing Assembly step-2 installation instruction 1 Assembly rubber crush-30,safety catch-right-29,sliding sleeve-27 on front guide rod-2. 2 Assembly rubber crush-30,safety catch-left-31,sliding sleeve-27 on front guide rod-2. 3 Assembly barbell bar-28 on sliding sleeve-27. 4 Assembly finish assmbly front guide rod-2 on ground tube-1 using M10*20 hexagon bolt-18,Φ10 washer-8,Φ 10 spring gasket-19.
  • Page 17 Assembly step-3 explosion drawing Description Note Qty. 3070 chin bar fix plate-bend 50 connect plate-2 hole 120*50*T3 hexagon bolt M10*20 spring gasket Φ10 washer Φ10 hexagon bolt M10*95 lock nut...
  • Page 18 Factory Assembly Drawing Description Note Qty. 3070 chin tube 3070 chin tube square tube 50*25 QTY:2PCS/SET plain half hexagon rivet nut...
  • Page 19 Assembly step（3）drawing Assembly step-3 installation instruction 1 Assembly fix plate-bend-17 on 3070 chin bar-49 using M10*20 hexagon bolt-18,Φ10 washer-8,Φ10 spring gasket-19. 2 Assembly 3070 chin bar-49 on front guide rod-2 using M10*20 hexagon bolt-18,Φ10 washer-8,Φ10 spring gasket-19. 3 Assembly 50 connect plate-2 hole-50,3070 chin bar-49 on left stand tube-3 using M10*95 hexagon bolt-7,Φ 10 washer-8,M10 lock nut-9 .
  • Page 20 Assembly step-4 explosion drawing Description Note Qty. up decorate plate 3070 back up connect frame hexagon bolt M10*80 washer Φ10 lock nut hexagon bolt M10*75...
  • Page 21 Factory Assembly Drawing Description Note Qty. back up connection tube decorate plate 3070 back up connect frame plain half hexagon rivet nut Mushroom head break mandrel QTY: 1PC/SET...
  • Page 22 Assembly step-4 drawing Assembly step-4 installation instruction 1 Assembly up decorate plate-53 on the two side of 3070 chin bar-49 using M10*75 hexagon bolt-56,Φ10 washer-8,M10 lock nut-9. 2 Assembly 3070 back up connect frame-54 on up decorate plate-53 using M10*80 hexagon bolt-55,Φ10 washer-8,M10 lock nut-9.
  • Page 23 Assembly step-5 explosion drawing 56 8 Description Note Qty. stainless guide-left sliding tube right stainless tube -right sliding tube -left chin up bar hexagon bolt M10*80 washer Φ10 lock nut hexagon bolt M10*75...
  • Page 24 Factory Assembly Drawing Description Note Qty. stainless front stand tube-right □50*50*2120 square tube □50*50*t1.2 stainless front stand tube-right QTY: 1PC/SET Description Note Qty. stainless front stand tube-left □50*50*2120 square tube □50*50*t1.2 stainless front stand tube-left QTY: 1PC/SET...
  • Page 25 Factory Assembly Drawing Description Note Qty. sliding sleeve bush bearing □60-□50 aluminium spring pin washer Φ10 hexagon bolt M10*45 lock nut pulley rotation cover Φ95 pulley powder metallurgy sleeve Φ33.2*Φ 29*Φ20*18 pulley rotation pin Φ20*M10*67 hexagon bolt M10*20 sliding sleeve spring gasket Φ10 QTY: 1PC/SET...
  • Page 26 Factory Assembly Drawing Description Note Qty. 3070 across connect plate hang ring washer Φ8 3070 across connect plate lock nut QTY: 1PCS/SET 32 circle tube plug high pull handle outer catch collar Φ38.6*Φ32.8*25 hexagon socket set screw M10*25...
  • Page 27 Assembly step- 5 drawing Assembly step-5 installation instruction 1 Put sliding tube right-61 on stainless tube -right-62. 2 Put sliding tube -left-63 on stainless guide-left-60. 3 Assembly stainless tube -right-62 on ground tube-1 using M10*75 hexagon bolt-56,Φ10 washer-8,M10 lock nut-9 . 4 Assembly stainless guide-left-60 on ground tube-1 using M10*75 hexagon bolt-56,Φ10 washer-8,M10 lock nut-9 .
  • Page 28 Assembly step-6 explosion drawing Description Note Qty. Φ95 pulley pulley frame decorate adjust plate Φ14*49*T1.5 powder metallurgy sleeve Φ20*Φ16*Φ10.5*21.5 hexagon bolt M10*75 lock nut wire-ball bolt washer Φ10...
  • Page 29 Factory Assembly Drawing Description Note Qty. Φ95 pulley pulley adjust plate hexagon bolt M10*45 pulley frame washer Φ10 lock nut QTY: 2PCS/SET Description Note Qty. 3070 wire gravity block bolt wire-splice head wire-head 54511 wire-ball head 54511 hexagon socket cap screws M5*25 3070 wire QTY: 2PCS/SET...
  • Page 30 Assembly step-6 drawing Assembly step-6 installation instruction 1 Assembly Φ95 pulley-71 on main machine using M10*75 hexagon bolt-56,powder metallurgy sleeve-87,M10 lock nut-9. 2 As shown in the figure through wire-ball bolt-88 then fix it on pulley frame-85,weight stack-130KG-33,sliding tube right-61. 3 As shown in the figure through wire-ball bolt-88 then fix it on pulley frame-85,weight stack-130KG-33,sliding tube -left-63.
  • Page 31 Assembly step-7 explosion drawing Description Note Qty. 3070 bottom reinforcing plate Φ95 pulley wire-hang nose wire-nose nose hexagon bolt M10*25 washer Φ10 lock nut powder metallurgy sleeve Φ20*Φ16*Φ10.5*21.5 hexagon bolt M10*75...
  • Page 32 Factory Assembly Drawing Description Note Qty. wire-nose nose wire-ball nose wire-nose nose QTY: 2PCS/SET...
  • Page 33 Assembly step-7 drawing Assembly step-7 installation instruction 1 Assembly 3070 bottom reinforcing plate-97 on ground tube-1 left stand tube-3 using M10*75 hexagon ， bolt-56,Φ10 washer-8,M10 lock nut-9 . 2 Assembly 3070 bottom reinforcing plate-97 on ground tube-1 right stand tube-5 using M10*75 hexagon ，...
  • Page 34 Assembly step-8 explosion drawing Description Note Qty. 3070 back shield shield rod washer Φ8 hexagon bolt M8*16...
  • Page 35 Assembly step-8 drawing Assembly step-8 installation instruction 1 Through shield rod-104 into 3070 back shield-103. 2 Assembly 3070 back shield-103 on fix plate-bend-17 using M8*16 hexagon bolt-105,Φ8 washer-79.
  • Page 36 Assembly step-9 explosion drawing Description Note Qty. 3035 barbell tube rotation tube L shape pin Φ17*250 barbell clamp hexagon socket button head screws M12*40 washer Φ12 spring gasket Φ12...
  • Page 37 Factory Assembly Drawing Description Note Qty. barbell bar plug Φ51*Φ 42.5*36.6L 3035 barbell tube aluminum inner catch collar Φ60*48.5*27L QTY: 2PCS/SET stainless tube-310 Φ50*310*t0.5 inner lining tube Φ48*298*t2.5 Description Note Qty. new rotation rod double barbell rotation powder metallurgy sleeve Φ50*Φ25*15 hexagon bolt M12*25...
  • Page 38 Assembly step-9 drawing Assembly step-9 installation instruction 1 Assembly rotation tube-107 on ground tube-1. 2 Assembly L shape pin-108 on ground tube-1. 3 Assembly 3035 barbell tube-106 on barbell bar-28 using M12*40 hexagon socket button head screws-110,Φ 12 washer-25 ,Φ12 spring gasket-24. 4 Assembly barbell clamp-109 on 3035 barbell tube-106...
  • Page 39 Assembly step-10 explosion drawing Description Note Qty. up connection tube up cross tube hook back stand tube concave plate 120*52*T3 hexagon bolt M10*75 washer Φ10 spring gasket Φ10 hexagon bolt M10*25 lock nut washer Φ8 hexagon bolt M10*70 lock nut hexagon bolt M12*25 spring gasket...
  • Page 40 Factory Assembly Drawing Description Note Qty. back connection tube Φ95 pulley hexagon bolt M10*45 washer Φ10 up connection tube lock nut QTY: 1PC/SET Description Note Qty. hook hook finger cover Φ8*100 QTY: 6PCS/SET...
  • Page 41 Factory Assembly Drawing Description Note Qty. 3070 back stand tube square tube □50*50*t1.5 back stand tube QTY: 2PCS/SET...
  • Page 42 Assembly step-10 drawing Assembly step-10 installation instruction 1 Assembly up connection tube-123 on main machine using M10*25 hexagon bolt-100,Φ10 washer-8,Φ10 spring gasket-19. 2 Assembly hook-125 on up cross tube-124 using Φ8 washer-79,M8 lock nut-80. 3 Assembly up cross tube-124 on up connection tube-123 using M10*70 hexagon bolt-10,Φ10 washer-8,M10 lock nut-9.
  • Page 43 Assembly step-11 explosion drawing Description Note Qty. barbell bar inner tube 3070 kettle fix frame 3070 small handle fix tube hexagon bolt M10*70 washer Φ10 lock nut hexagon bolt M10*16...
  • Page 44 Factory Assembly Drawing Description Note Qty. kettle frame fix plate cross recessed countersunk head M6*12 3070 kettle fix frame QTY: 1PC/SET Description Note Qty. small handle rubber ring 3070 small handle fix tube QTY: 1PC/SET...
  • Page 45 Factory Assembly Drawing Description Note Qty. aluminium cap Φ50*Φ11*11 outer cover tube stainless outer tube Φ50*0.8*200 barbell bar inner tube hexagon socket button head screws M10*30 QTY: 10PCS/SET barbell bar tube rubber gasket Φ70*Φ50*10...
  • Page 46 Assembly step-11 drawing Assembly step-11 installation instruction 1 Assembly barbell bar inner tube-132 on up cross tube-124 using M10*16 hexagon bolt-12,Φ10 washer-8. 2 Assembly 3070 kettle fix frame-133 on up cross tube-124 using M10*70 hexagon bolt-10,Φ10 washer-8,M10 lock nut-9. 3 Assembly 3070 small handle fix tube-134 on up cross tube-124 using M10*70 hexagon bolt-10,Φ10 washer- 8,M10 lock nut-9.
  • Page 47 Assembly step-12 explosion drawing Description Note Qty. ball shape chin up bar hexagon bolt M10*25 washer Φ10 spring gasket Φ10 hexagon bolt M10*80 lock nut butterfly clip Φ50...
  • Page 48 Factory Assembly Drawing Description Note Qty. ball shape chin up bar 32 circle tube plug ball shape chin up bar QTY: 2PCS/SET...
  • Page 49 Assembly step-12 drawing Assembly step-12 installation instruction 1 Assembly ball shape chin up bar-146 on up decorate plate-53 using M10*80 hexagon bolt-55,M10*25 hexagon bolt-100,Φ10 washer-8,Φ10 spring gasket-19,M10 lock nut-9. 2 Assembly butterfly clip-147 on barbell bar inner tube-132.
  • Page 50 Assembly step-13 explosion drawing Description Note Qty. right safety catch-long rubber right safety catch 3070 footplate 3070 back support pad move hook move hook-right short safety catch-left short safety catch 85 T shape pin-black leg press safety catch leg curl tube 100 T shape pin-black...
  • Page 51 Factory Assembly Drawing Description Note Qty. long safety catch-right long safety catch-outer rubber long safety catch-right QTY: 1PC/SET right safety catch Description Note Qty. long safety catch-right welding QTY: 1PC/SET long safety catch-outer rubber 387mm...
  • Page 52 Factory Assembly Drawing Description Note Qty. back support tube 3070 waist pad hexagon bolt M8*70 3070 back support pad washer Φ8 QTY: 1PC/SET Description Note Qty. 3070 footplate 3070 footplate lock pin-40 QTY: 1PC/SET...
  • Page 53 Factory Assembly Drawing Description Note Qty. 3070 short safety catch -right roller shaft bearing 190 safety catch rubber hexagon socket button head screws M10*110 washer Φ10 spring gasket Φ10 short safety catch countersunk head socket head M6*10 QTY: 1PC/SET Description Note Qty.
  • Page 54 Factory Assembly Drawing Description Note Qty. move hook hook connect shaft powder metallurgy sleeve washer Φ10 lock nut spring gasket move hook move hook plate hexagon socket button head bolt M8*40 QTY: 1PC/SET lock nut washer Φ8 Description Note Qty. move hook-right hook connect shaft move hook-right...
  • Page 55 部 件 分 装 爆 炸 图 Description Note Qty. 3070 leg press safety catch 85 new safety catch rubber 3070 leg press safety catch QTY: 1PC/SET Description Note Qty. leg press adjust frame pull pin leg press adjust frame sponge Φ100*Φ25*175 QTY: 1PC/SET...
  • Page 56 Assembly step-13 drawing Assembly step-13 installation instruction 1 Assembly 3070 back support pad-152 on stainless guide-left-60 stainless tube -right-62 using 85 T shape ， pin-black-157. 2 Assembly leg curl tube-159 on leg press safety catch-158 using M10*25 hexagon bolt-100. 3 As shown in the figure assembly all parts on main machine.
  • Page 57 EXTRA PARTS knurling short handle aluminium alloy across rod QTY: 1PCS/SET QTY: 1PCS/SET long handle sawtooth long handle stand footplate QTY: 1PCS/SET QTY: 1PCS/SET QTY: 1PCS/SET triangle triceps handle knurling handle triangle handle chain hook QTY: 1PCS/SET QTY: 2PCS/SET QTY: 1PCS/SET QTY: 7PCS/SET arch high pull handle normal handle...
  • Page 58 Factory Assembly Drawing Description Note Qty. big handle 32 circle tube plug long handle QTY: 1PC/SET Description Note Qty. inner shaft Φ20*137*M10 3070 handle frame powder metallurgy sleeve Φ33.2*Φ 29*Φ20*18 handle tube spring gasket Φ10 washer Φ10 hexagon socket button head screws M10*25 knurling handle QTY: 2PCS/SET Description...
  • Page 59 Factory Assembly Drawing Description Note Qty. across rod spring catch collar inner lining tube inner shaft Φ17*38 washer bearing 6001-2RS bearing sleeve T shape pin T shape lining sleeve U shape fastener catch hexagon socket button head screws M8*16 aluminium alloy across rod washer Φ8 QTY: 1PC/SET...
  • Page 60 Factory Assembly Drawing triangle handle QTY: 1PC/SET Description Note Qty. triangular handle 32 tube plug...
  • Page 61 This Release includes, but is not limited to, any risks, dangers, or injuries including death caused by the negligence of Force USA, LLC or others, and is to the fullest extent permitted by law.
