MVI56E-LDM-MQTT ♦ MQ Telemetry Transport
ControlLogix® Platform
5.3

Ignition

Ignition requires that MQTT-related modules be installed for the LDM_MQTT module's
Sparkplug communications requirements. This is a trial version of Ignition lasts two
hours. It can be restarted any number of times.
1 Go to the following website to study Ignition to provide you with an overall view of
the tool:
https://docs.inductiveautomation.com/display/DOC80/Introducing+Ignition
2 Navigate to the following website to download and install (selecting the default
options) Ignition v8.0.12 (current as of this publication).
https://inductiveautomation.com/downloads/
3 From the following web link:
party-modules/8.0.11
Modules for Ignition.

MQTT Distributor Module (30.5 MB)
https://files.inductiveautomation.com/third-party/cirrus-link/4.0.3/MQTT-
Distributor-signed.modl

MQTT Engine Module (25.7 MB)
https://files.inductiveautomation.com/third-party/cirrus-link/4.0.3/MQTT-
Engine-signed.modl

MQTT Transmission Module (21.8 MB)
https://files.inductiveautomation.com/third-party/cirrus-link/4.0.3/MQTT-
Transmission-signed.modl
Note: Make note of where these module files were saved.

5.3.1 Installing .modl Files

Once Ignition running, select the Config gear icon (left side of the window). Sign in as
required. When the Configuration menu options display:
1 Select the S
2 Scroll to the bottom of the page and select the I
link.
3 Navigate to the MQTT Module (*.modl files) storage locations, and follow the web
instructions for installing them into the Ignition Gateway.
ProSoft Technology, Inc.
https://inductiveautomation.com/downloads/third-
download the following Cirrus Link Solutions MQTT
/M option.
YSTEM ODULES
MQTT SparkplugB Example
Quick Start Guide
U
NSTALL OR PGRADE A
Page 27 of 55
...
M
ODULE
