Configuring the MVI56E-LDM's EtherNet/IP Address

3.3
Configure the MVI56E-LDM's Ethernet port IP addresses by modifying the
/etc/network/interfaces file on the module. Refer to Figure 1 for a sample
communication topology.
Refer to the MVI56E-LDM Developer Manual
interfaces file. Use an FTP client such as
of the Interfaces file.
Interfaces file
Parameters
# We always want the loopback interface.
#
auto lo
iface lo loopback
#An example Ethernet card setup:
(broadcast and gateway are optional)
#
auto
iface eth0
address
network
netmask
broadcast
#gateway
auto
iface eth1
address
network
netmask
broadcast
gateway
ProSoft Technology, Inc.
for detailed information about the
WinSCP to edit the
TM
Values
eth0
inet static
102.168.0.188
192.168.0.0
255.255.255.0
192.168.0.255
192.169.0.1
eth1
inet static
192.168.4.188
192.168.4.0
255.255.255.0
192.168.4.255
192.168.4.1
Figure 4: Network Interfaces
Connecting to the MVI56E-LDM Module
Quick Start Guide
eth0 and eth1
