MVI56E-LDM-MQTT ♦ MQ Telemetry Transport
ControlLogix® Platform
4.4

Encrypted Data Exchange

Edit the config.json file's parameter values in the MVI56E-LDM module
1
according to the Values for Encrypted messaging column indicated in the table
on page 15 (MQTT Generic config.json File).
2 Reboot the MVI56E-LDM module.
3 Edit the MQTT Explorer by activating the Encryption and set Port to 8883.
4 Click Save, then Connect.
5 In the search field, type PSFT so the MQTT Explorer can show the PSFT topic
coming from the MVI56E-LDM module.
6 Observe the values of the six tags/variables change every few seconds.
ProSoft Technology, Inc.
Figure 17: MQTT Explorer Client Connections Dialog
Figure 18: Search for PSFT
MQTT Generic Type Sample Application
Quick Start Guide
Page 22 of 55
