Preparation
f r o n t
upper air filter
(behind the grille)
upper air intake
drain outlet
air outlet
lower air filter
lower air intake
drain outlet
(only for pump
heating mode)
power cord buckle
power cord outlet
power plug socket
bottom tray
drain outlet
control panel
horizontal louver
blade
(swing automatically)
handle
(both sides)
Panel
Caster
vent control
r e a r
M O D E A L B
upper air filter
(behind the grille)
upper air intake
drain outlet
air outlet
lower air filter
lower air intake
drain outlet
(only for pump
heating mode)
power cord buckle
power cord outlet
power plug socket
bottom tray
drain outlet
